Part Details for SMDA24C-5.TBT by Semtech Corporation
Results Overview of SMDA24C-5.TBT by Semtech Corporation
- Distributor Offerings: (7 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
SMDA24C-5.TBT Information
SMDA24C-5.TBT by Semtech Corporation is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for SMDA24C-5.TBT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
37K8450
|
Newark | Transient Suppressor Diode Array, bidirectional,24V V(Rwm),so Rohs Compliant: Yes |Semtech SMDA24C-5.TBT RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1000 |
|
$1.2500 | Buy Now |
|
DISTI #
SMDA24C-5.TBTCT-ND
|
DigiKey | TVS DIODE 24VWM 43VC 8-SO Min Qty: 1 Lead time: 13 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1335 In Stock |
|
$1.3250 / $3.9400 | Buy Now |
|
DISTI #
947-SMDA24C-5.TBT
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes 24V, 5 CHAN, TVS ARRAY RoHS: Compliant | 1058 |
|
$1.3200 / $3.8200 | Buy Now |
|
|
Bristol Electronics | 102 |
|
RFQ | ||
|
|
Rochester Electronics | TVS Diode Zener Bi-Directional 24V (Max) 43V 8-SOIC T/R RoHS: Compliant Status: Active Min Qty: 1 | 2000 |
|
$1.1100 / $1.3900 | Buy Now |
|
DISTI #
SMDA24C-5.TBT
|
Avnet Silica | Diode TVS Quad Common Cathode BiDir 24V 300W 8Pin SO TR (Alt: SMDA24C-5.TBT) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 15 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Braemac Americas-Symmetry | 24V, 5 CHAN, TVS ARRAY Min Qty: 1 | 0 |
|
$1.2932 / $1.4310 | Buy Now |
Part Details for SMDA24C-5.TBT
SMDA24C-5.TBT CAD Models
SMDA24C-5.TBT Part Data Attributes
|
|
SMDA24C-5.TBT
Semtech Corporation
Buy Now
Datasheet
|
Compare Parts:
SMDA24C-5.TBT
Semtech Corporation
Trans Voltage Suppressor Diode, 300W, 24V V(RWM), Bidirectional, 6 Element, Silicon, MS-012AA, ROHS COMPLIANT, SOIC-8
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | SEMTECH CORP | |
| Part Package Code | SOIC | |
| Package Description | ROHS COMPLIANT, SOIC-8 | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 4 Weeks | |
| Samacsys Manufacturer | SEMTECH | |
| Additional Feature | HIGH RELIABILITY, LOW LEAKAGE CURRENT | |
| Breakdown Voltage-Min | 26.7 V | |
| Breakdown Voltage-Nom | 26.7 V | |
| Clamping Voltage-Max | 43 V | |
| Configuration | COMMON CATHODE, 6 ELEMENTS | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JEDEC-95 Code | MS-012AA | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Peak Rev Power Dis-Max | 300 W | |
| Number of Elements | 6 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | BIDIRECTIONAL | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 24 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL |
