SMBJ30CAQ-13-F Information
SMBJ30CAQ-13-F by Diodes Incorporated is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for SMBJ30CAQ-13-F
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
29AK7788
|
Newark | Tvs Diode, Bidir, 30V, Smb Rohs Compliant: Yes |Diodes Inc. SMBJ30CAQ-13-F RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 773 |
|
$0.1430 / $0.3800 | Buy Now |
|
DISTI #
SMBJ30CAQ-13-FDICT-ND
|
DigiKey | TVS DIODE 30VWM 48.4VC SMB Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1844 In Stock |
|
$0.1149 / $0.6700 | Buy Now |
|
DISTI #
SMBJ30CAQ-13-F
|
Avnet Americas | Diode TVS Single Bi-Direction 30V 600W 2-Pin DO-214AA T/R - Tape and Reel (Alt: SMBJ30CAQ-13-F) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks, 0 Days Container: Reel | 0 |
|
$0.0899 / $0.0917 | Buy Now |
|
DISTI #
621-SMBJ30CAQ-13-F
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes 600W Transient Voltage Suppressor RoHS: Compliant | 845 |
|
$0.1140 / $0.4800 | Buy Now |
|
DISTI #
V72:2272_22870533
|
Arrow Electronics | TVS Diode Single Bi-Dir 30V 600W Automotive AEC-Q101 2-Pin SMB T/R Min Qty: 647 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2229 Container: Cut Strips | Americas - 1094 |
|
$0.1138 / $0.1447 | Buy Now |
|
DISTI #
SMBJ30CAQ-13-F
|
TME | Diode: TVS, reel,tape Min Qty: 1 | 0 |
|
$0.1240 / $0.5900 | RFQ |
|
DISTI #
SMBJ30CAQ-13-F
|
IBS Electronics | SMBJ SERIES 30 V 600 W BI-DIRECTIONAL SURFACE MOUNT TVS DIODE - SMB (DO-214AA) Min Qty: 3000 Package Multiple: 1 | 0 |
|
$0.1261 / $0.1352 | Buy Now |
|
DISTI #
SMC-SMBJ30CAQ-13-F
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 1104122 |
|
RFQ | |
|
DISTI #
SMBJ30CAQ-13-F
|
Avnet Silica | Diode TVS Single BiDirection 30V 600W 2Pin DO214AA TR (Alt: SMBJ30CAQ-13-F) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Cytech Systems Limited | TVS DIODE 30VWM 48.4VC SMB | 3000 |
|
RFQ |
Part Details for SMBJ30CAQ-13-F
SMBJ30CAQ-13-F CAD Models
SMBJ30CAQ-13-F Part Data Attributes
|
|
SMBJ30CAQ-13-F
Diodes Incorporated
Buy Now
Datasheet
|
Compare Parts:
SMBJ30CAQ-13-F
Diodes Incorporated
Trans Voltage Suppressor Diode,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | DIODES INC | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 12 Weeks | |
| Date Of Intro | 2018-10-24 | |
| Samacsys Manufacturer | Diodes Incorporated | |
| Additional Feature | EXCELLENT CLAMPING CAPABILITY | |
| Breakdown Voltage-Max | 38.3 V | |
| Breakdown Voltage-Min | 33.3 V | |
| Breakdown Voltage-Nom | 35.8 V | |
| Clamping Voltage-Max | 48.4 V | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Peak Rev Power Dis-Max | 600 W | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | BIDIRECTIONAL | |
| Power Dissipation-Max | 5 W | |
| Reference Standard | AEC-Q101; IATF 16949; MIL-STD-202 | |
| Rep Pk Reverse Voltage-Max | 30 V | |
| Reverse Current-Max | 5 µA | |
| Reverse Test Voltage | 30 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | C BEND | |
| Terminal Position | DUAL |
