3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for SMAJ33CA by Vishay Intertechnologies
Results Overview of SMAJ33CA by Vishay Intertechnologies
- Distributor Offerings: (1 listing)
- Number of FFF Equivalents: (7 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
SMAJ33CA Information
SMAJ33CA by Vishay Intertechnologies is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for SMAJ33CA
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
78-SMAJ33CA
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes 400W 33V 5% Bi RoHS: Compliant | 4597 |
|
$0.0830 / $0.4900 | Buy Now |
Part Details for SMAJ33CA
SMAJ33CA CAD Models
SMAJ33CA Part Data Attributes
|
|
SMAJ33CA
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
SMAJ33CA
Vishay Intertechnologies
Trans Voltage Suppressor Diode, 33V V(RWM), Bidirectional,
|
| Rohs Code | No | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | SMA, 2 PIN | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Samacsys Manufacturer | Vishay | |
| Breakdown Voltage-Max | 44.9 V | |
| Breakdown Voltage-Min | 36.7 V | |
| Breakdown Voltage-Nom | 38.6 V | |
| Clamping Voltage-Max | 53.3 V | |
| Configuration | SINGLE | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JEDEC-95 Code | DO-214AC | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e0 | |
| Non-rep Peak Rev Power Dis-Max | 400 W | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Polarity | BIDIRECTIONAL | |
| Rep Pk Reverse Voltage-Max | 33 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | Tin/Lead (Sn/Pb) | |
| Terminal Form | C BEND | |
| Terminal Position | DUAL |
Alternate Parts for SMAJ33CA
This table gives cross-reference parts and alternative options found for SMAJ33CA. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of SMAJ33CA, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| SMAJ33CA | Sensitron Semiconductors | Check for Price | Trans Voltage Suppressor Diode, 400W, 33V V(RWM), Bidirectional, 1 Element, Silicon, DO-214AC, PLASTIC, SMA, 2 PIN | SMAJ33CA vs SMAJ33CA |
| P4SMAJ33C | Surge Components Inc | Check for Price | Trans Voltage Suppressor Diode, Unidirectional, 1 Element, Silicon, DO-214AC, PLASTIC, SMA, 2 PIN | SMAJ33CA vs P4SMAJ33C |
| SMAJ33C-T | Micro Commercial Components | Check for Price | Transient Suppressor, | SMAJ33CA vs SMAJ33C-T |
| SMAJ33CA-7 | Diodes Incorporated | Check for Price | Trans Voltage Suppressor Diode, 400W, 33V V(RWM), Bidirectional, 1 Element, Silicon, PLASTIC, SMA, 2 PIN | SMAJ33CA vs SMAJ33CA-7 |
| P4SMAJ33CA | Surge Components Inc | Check for Price | Trans Voltage Suppressor Diode, Unidirectional, 1 Element, Silicon, DO-214AC, PLASTIC, SMA, 2 PIN | SMAJ33CA vs P4SMAJ33CA |
| SMAJ33C | Vishay Intertechnologies | Check for Price | Trans Voltage Suppressor Diode, 400W, 33V V(RWM), Bidirectional, 1 Element, DO-214AC, SMA, 2 PIN | SMAJ33CA vs SMAJ33C |
| SMAJ33C-GT3 | Sangdest Microelectronics (Nanjing) Co Ltd | Check for Price | Trans Voltage Suppressor Diode, 400W, 33V V(RWM), Bidirectional, 1 Element, Silicon, DO-214AC, LEAD FREE, PLASTIC, SMA, 2 PIN | SMAJ33CA vs SMAJ33C-GT3 |
SMAJ33CA Frequently Asked Questions (FAQ)
-
The recommended footprint for SMAJ33CA is a standard DO-214AC package with a pad size of 2.5mm x 1.5mm and a spacing of 1.5mm between pads.
-
Yes, SMAJ33CA is a high-reliability device that meets the requirements of AEC-Q101 and is suitable for use in automotive and other high-reliability applications.
-
SMAJ33CA is designed to handle high surge currents, with a peak pulse current rating of 3000A (8/20μs) and a clamping voltage of 33V.
-
Yes, SMAJ33CA is compatible with lead-free soldering and meets the requirements of RoHS and WEEE directives.
-
The operating temperature range of SMAJ33CA is -55°C to 150°C, making it suitable for use in a wide range of applications.
