SM24CANA-02HTG Information
SM24CANA-02HTG by Littelfuse Inc is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for SM24CANA-02HTG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
18AC7726
|
Newark | Tvs Diode, 200W, 24V, Bidir, Sot23, Product Range:Spa Sm24Cana Series, Tvs Polarity:Bidirectional, Reverse Stand-Off Voltage Vrwm:24V, Clamping Voltage Vc Max:50V, Diode Case Style:Sot-23, No. Of Pins:3Pins, Breakdown Voltage Rohs Compliant: Yes |Littelfuse SM24CANA-02HTG RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 0 |
|
$0.2700 / $0.5490 | Buy Now |
|
DISTI #
86X1744
|
Newark | Tvs Array, 200W, 26.7V, Bi-Directional, Sot-23, Product Range:Spa Sm24Cana Series, Tvs Polarity:Bidirectional, Reverse Standoff Voltage:24V, Clamping Voltage Max:50V, Diode Case Style:Sot-23, No. Of Pins:3Pins, Qualification:Aec-Q101Rohs Compliant: Yes |Littelfuse SM24CANA-02HTG RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1980 / $0.2640 | Buy Now |
|
DISTI #
F6449CT-ND
|
DigiKey | TVS DIODE 24VWM 50VC SOT23-3 Min Qty: 1 Lead time: 11 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
8073 In Stock |
|
$0.1875 / $0.5300 | Buy Now |
|
DISTI #
576-SM24CANA-02HTG
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes 400W 24V 2 Ch ESD Prot RoHS: Compliant | 27773 |
|
$0.1870 / $0.5300 | Buy Now |
|
DISTI #
V72:2272_06468490
|
Arrow Electronics | ESD Suppressor TVS Bi-Dir 24V 3-Pin SOT-23 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks Date Code: 2237 Container: Cut Strips | Americas - 78 |
|
$0.2013 / $0.3253 | Buy Now |
|
|
Future Electronics | SM24CANA Series 26.7 V 3 A 200 W Dual Bi-Directional TVS Diode - SOD-23-3 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 11 Weeks Container: Reel | 39000Reel |
|
$0.1750 / $0.1820 | Buy Now |
|
|
Future Electronics | SM24CANA Series 26.7 V 3 A 200 W Dual Bi-Directional TVS Diode - SOD-23-3 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 11 Weeks Container: Reel | 0Reel |
|
$0.1750 / $0.1820 | Buy Now |
|
DISTI #
68039737
|
Verical | ESD Suppressor TVS Bi-Dir 24V 3-Pin SOT-23 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2306 | Americas - 27000 |
|
$0.2399 / $0.2991 | Buy Now |
|
DISTI #
69686965
|
Verical | ESD Suppressor TVS Bi-Dir 24V 3-Pin SOT-23 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 277 Package Multiple: 1 Date Code: 2301 | Americas - 3000 |
|
$0.2567 / $0.2837 | Buy Now |
|
DISTI #
64950514
|
Verical | ESD Suppressor TVS Bi-Dir 24V 3-Pin SOT-23 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 277 Package Multiple: 1 Date Code: 2201 | Americas - 3000 |
|
$0.2567 / $0.2837 | Buy Now |
Part Details for SM24CANA-02HTG
SM24CANA-02HTG CAD Models
SM24CANA-02HTG Part Data Attributes
|
|
SM24CANA-02HTG
Littelfuse Inc
Buy Now
Datasheet
|
Compare Parts:
SM24CANA-02HTG
Littelfuse Inc
Trans Voltage Suppressor Diode, 200W, 24V V(RWM), Unidirectional, 2 Element, Silicon, TO-236AB, TO-236, 3 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LITTELFUSE INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Samacsys Manufacturer | LITTELFUSE | |
| Breakdown Voltage-Min | 26.7 V | |
| Configuration | COMPLEX | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JEDEC-95 Code | TO-236AB | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Peak Rev Power Dis-Max | 200 W | |
| Number of Elements | 2 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Reference Standard | AEC-Q101 | |
| Rep Pk Reverse Voltage-Max | 24 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
SM24CANA-02HTG Frequently Asked Questions (FAQ)
-
The recommended storage temperature for SM24CANA-02HTG is -40°C to 125°C, as per the manufacturer's guidelines.
-
Yes, SM24CANA-02HTG is designed to withstand high-vibration environments. However, it's essential to follow proper mounting and installation procedures to ensure reliable performance.
-
Yes, SM24CANA-02HTG is compatible with lead-free soldering processes, making it suitable for modern manufacturing requirements.
-
The typical response time for SM24CANA-02HTG is around 1-2 microseconds, depending on the specific application and operating conditions.
-
SM24CANA-02HTG is rated for operation up to 150°C, making it suitable for high-temperature applications. However, it's essential to consider derating and thermal management to ensure reliable performance.
