SL3007-TP Information
SL3007-TP by Micro Commercial Components is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for SL3007-TP
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
353-SL3007-TPCT-ND
|
DigiKey | P-CHANNEL MOSFET, SOT-23-3L Min Qty: 1 Lead time: 18 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
5926 In Stock |
|
$0.0740 / $0.4900 | Buy Now |
|
DISTI #
833-SL3007-TP
|
Mouser Electronics | MOSFETs P-CHANNEL MOSFET, SOT-23-3L | 2685 |
|
$0.0730 / $0.4900 | Buy Now |
Part Details for SL3007-TP
SL3007-TP CAD Models
SL3007-TP Part Data Attributes
|
|
SL3007-TP
Micro Commercial Components
Buy Now
Datasheet
|
Compare Parts:
SL3007-TP
Micro Commercial Components
Power Field-Effect Transistor, 7A I(D), 30V, 0.036ohm,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICRO COMMERCIAL COMPONENTS CORP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | MCC | |
| DS Breakdown Voltage-Min | 30 V | |
| Drain Current-Max (ID) | 7 A | |
| Drain-source On Resistance-Max | 0.036 Ω | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Terminal Finish | Tin (Sn) |
