SISS26LDN-T1-GE3 Information
SISS26LDN-T1-GE3 by Vishay Intertechnologies is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for SISS26LDN-T1-GE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
06AH4241
|
Newark | Mosfet, N-Ch, 60V, 81.2A, 150Deg C, 57W, Transistor Polarity:N Channel, Continuous Drain Current Id:81.2A, Drain Source Voltage Vds:60V, On Resistance Rds(On):0.0034Ohm, Rds(On) Test Voltage Vgs:10V, Threshold Voltage Vgs:2.5V, Powerrohs Compliant: Yes |Vishay SISS26LDN-T1-GE3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 15835 |
|
$0.9550 / $1.7300 | Buy Now |
|
DISTI #
SISS26LDN-T1-GE3
|
Avnet Americas | Power MOSFET, N Channel, 60 V, 81.2 A, 0.0034 ohm, PowerPAK 1212, Surface Mount - Tape and Reel (Alt: SISS26LDN-T1-GE3) RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 16 Weeks, 0 Days Container: Reel | 0 |
|
$0.4560 / $0.4688 | Buy Now |
|
DISTI #
78-SISS26LDN-T1-GE3
|
Mouser Electronics | MOSFETs Nch 60V Vds 20V Vgs PowerPAK 1212-8S RoHS: Compliant | 179978 |
|
$0.4950 / $1.4600 | Buy Now |
|
DISTI #
SISS26LDN-T1-GE3
|
TTI | MOSFETs Nch 60V Vds 20V Vgs PowerPAK 1212-8S RoHS: Compliant pbFree: Pb-Free Min Qty: 6000 Package Multiple: 3000 Container: Reel | Americas - 0 |
|
$0.4570 / $0.4950 | Buy Now |
|
DISTI #
SISS26LDN-T1-GE3
|
TME | Transistor: N-MOSFET, TrenchFET®, unipolar, 60V, 65A, Idm: 150A, 36W Min Qty: 1 | 0 |
|
$0.7100 / $1.0600 | RFQ |
|
|
LCSC | 60V 81.2A 36W 0.00434.5V10A 2.5V 1 N-channel MOSFETs ROHS | 42 |
|
$0.9143 / $0.9596 | Buy Now |
|
|
Vyrian | Transistors | 49785 |
|
RFQ |
Part Details for SISS26LDN-T1-GE3
SISS26LDN-T1-GE3 CAD Models
SISS26LDN-T1-GE3 Part Data Attributes
|
|
SISS26LDN-T1-GE3
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
SISS26LDN-T1-GE3
Vishay Intertechnologies
Power Field-Effect Transistor,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 16 Weeks | |
| Date Of Intro | 2019-01-09 | |
| Samacsys Manufacturer | Vishay | |
| Avalanche Energy Rating (Eas) | 31.2 mJ | |
| Case Connection | DRAIN | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 60 V | |
| Drain Current-Max (ID) | 81.2 A | |
| Drain-source On Resistance-Max | 0.0043 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 24 pF | |
| JESD-30 Code | S-PDSO-F8 | |
| Number of Elements | 1 | |
| Number of Terminals | 8 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 57 W | |
| Pulsed Drain Current-Max (IDM) | 150 A | |
| Surface Mount | YES | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON | |
| Turn-off Time-Max (toff) | 68 ns | |
| Turn-on Time-Max (ton) | 188 ns |
