SGP400TZ Information
SGP400TZ by Rochester Electronics LLC is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Part Details for SGP400TZ
SGP400TZ CAD Models
SGP400TZ Part Data Attributes
|
|
SGP400TZ
Rochester Electronics LLC
Buy Now
Datasheet
|
Compare Parts:
SGP400TZ
Rochester Electronics LLC
SWITCHING CONTROLLER, 68kHz SWITCHING FREQ-MAX, PDSO6, LEAD FREE, SOT-26, 6 PIN
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROCHESTER ELECTRONICS LLC | |
| Part Package Code | SOT | |
| Package Description | LEAD FREE, SOT-26, 6 PIN | |
| Pin Count | 6 | |
| Reach Compliance Code | unknown | |
| Samacsys Manufacturer | Rochester Electronics | |
| Analog IC - Other Type | SWITCHING CONTROLLER | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 20 V | |
| Input Voltage-Min | 8.5 V | |
| Input Voltage-Nom | 15 V | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e3 | |
| Length | 2.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -20 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1.45 mm | |
| Surface Mount | YES | |
| Switcher Configuration | SINGLE | |
| Switching Frequency-Max | 68 kHz | |
| Temperature Grade | OTHER | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.95 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.6 mm |
Alternate Parts for SGP400TZ
This table gives cross-reference parts and alternative options found for SGP400TZ. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of SGP400TZ, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| SGP400TZ | Fairchild Semiconductor Corporation | Check for Price | AC-DC Linear Regulators, 6LD, SUPERSOT, JEDEC MO-193, 1.6MM WIDE, 3000/TAPE REEL | SGP400TZ vs SGP400TZ |
