SDR0403-681KL by: Bourns Inc

General Purpose Inductor, 680uH, 10%, 1 Element, Ferrite-Core, SMD, 1816, ROHS COMPLIANT

Part Details for SDR0403-681KL by Bourns Inc

Results Overview of SDR0403-681KL by Bourns Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Energy and Power Systems Transportation and Logistics Renewable Energy Automotive

SDR0403-681KL Information

SDR0403-681KL by Bourns Inc is a Fixed Inductor.
Fixed Inductors are under the broader part category of Inductors.

Inductors are passive components that resist sudden changes in current by storing and releasing energy in an electromagnetic fiel. They are often used in power circuits and energy storage. Read more about Inductors on our Inductors part category page.

Price & Stock for SDR0403-681KL

Part # Distributor Description Stock Price Buy
DISTI # 04P1905
Newark Inductor, Un-Shielded, 680Uh, 160Ma, Smd, Inductance:680Μh, Rms Current (Irms):110Ma, Inductor Construction:Unshielded, Saturation Current (Isat):160Ma, Product Range:Sdr0403 Series, Dc Resistance Max:8.6Ohm, Product Length:4.5Mm Rohs Compliant: Yes |Bourns SDR0403-681KL RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 0 Container: Cut Tape 0
  • 100 $0.2750
$0.2750 Buy Now
DISTI # 61J8054
Newark Bourns Part Rohs Compliant: Yes |Bourns SDR0403-681KL RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 1 $0.2700
  • 5,000 $0.2640
  • 10,000 $0.2440
  • 20,000 $0.2270
  • 30,000 $0.2120
  • 50,000 $0.2020
$0.2020 / $0.2700 Buy Now
DISTI # SDR0403-681KLCT-ND
DigiKey FIXED IND 680UH 110MA 8.6OHM SMD Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 1755
In Stock
  • 1 $0.4500
  • 10 $0.3670
  • 100 $0.3017
  • 1,000 $0.2481
  • 2,000 $0.2339
  • 4,000 $0.2206
  • 6,000 $0.2132
  • 10,000 $0.2041
  • 14,000 $0.1984
  • 20,000 $0.1925
  • 50,000 $0.1913
$0.1913 / $0.4500 Buy Now
DISTI # SDR0403-681KL
Avnet Americas Power Inductor (SMD), 680 uH, ? 10%, 110 mA, Unshielded, 160 mA, 4.5mm x 4mm x 3.2mm - Tape and Reel (Alt: SDR0403-681KL) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 12 Weeks, 0 Days Container: Reel 0
  • 2,000 $0.1859
  • 4,000 $0.1704
  • 8,000 $0.1683
  • 12,000 $0.1661
  • 16,000 $0.1640
$0.1640 / $0.1859 Buy Now
DISTI # 652-SDR0403-681KL
Mouser Electronics Power Inductors - SMD 680uH 10% SMD 0403 RoHS: Compliant 1026
  • 1 $0.4000
  • 10 $0.3670
  • 100 $0.3020
  • 1,000 $0.2410
  • 2,000 $0.2210
  • 4,000 $0.2080
  • 10,000 $0.2000
$0.2000 / $0.4000 Buy Now
DISTI # V72:2272_06260355
Arrow Electronics Inductor Power Unshielded Wirewound 680uH 10% 1KHz 40Q-Factor Ferrite 0.11A 8.6Ohm DCR T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 1809 Container: Cut Strips Americas - 3
Buy Now
DISTI # 70411043
RS SDR0403 WireWound SMDinductor w/ FerriteCore,680 uH +/-10%WireWound 110mA Idc Min Qty: 250 Package Multiple: 1 Container: Bulk 0
  • 250 $0.2930
  • 2,500 $0.2790
  • 12,500 $0.2640
  • 25,000 $0.2490
$0.2490 / $0.2930 RFQ
Onlinecomponents.com Inductor Power Wirewound 680uH 10% 1KHz 40Q-Factor Ferrite 110mA 8.6Ohm DCR T/R RoHS: Compliant 0
  • 2,000 $0.2284
  • 4,000 $0.2217
  • 6,000 $0.2155
  • 8,000 $0.2096
  • 10,000 $0.2064
  • 26,000 $0.2013
  • 50,000 $0.1962
$0.1962 / $0.2284 Buy Now
Bristol Electronics   606
RFQ
Quest Components   484
  • 1 $0.9580
  • 105 $0.4790
  • 419 $0.3832
$0.3832 / $0.9580 Buy Now
DISTI # SDR0403-681KL
TTI Power Inductors - SMD 680uH 10% SMD 0403 pbFree: Pb-Free Min Qty: 2000 Package Multiple: 2000 Container: Reel Americas - 0
  • 2,000 $0.2370
$0.2370 Buy Now
DISTI # SDR0403-681KL
Avnet Abacus Power Inductor SMD 680 uH 10 110 mA Unshielded 160 mA 45mm x 4mm x 32mm - Tape and Reel (Alt: SDR0403-681KL) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 13 Weeks, 0 Days Container: Reel Abacus - 0
Buy Now
Master Electronics Inductor Power Wirewound 680uH 10% 1KHz 40Q-Factor Ferrite 110mA 8.6Ohm DCR T/R RoHS: Compliant 0
  • 2,000 $0.2284
  • 4,000 $0.2217
  • 6,000 $0.2155
  • 8,000 $0.2096
  • 10,000 $0.2064
  • 26,000 $0.2013
  • 50,000 $0.1962
$0.1962 / $0.2284 Buy Now

Part Details for SDR0403-681KL

SDR0403-681KL Part Data Attributes

Parametric Data
SDR0403-681KL Bourns Inc
Buy Now Datasheet
Compare Parts:
SDR0403-681KL Bourns Inc General Purpose Inductor, 680uH, 10%, 1 Element, Ferrite-Core, SMD, 1816, ROHS COMPLIANT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer BOURNS INC
Package Description CHIP
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8504.50.80.00
Factory Lead Time 12 Weeks
Samacsys Manufacturer Bourns
Case/Size Code 1816
Construction Rectangular
Core Material FERRITE
DC Resistance 8.6 Ω
Inductance-Nom (L) 680 µH
Inductor Application POWER INDUCTOR
Inductor Type GENERAL PURPOSE INDUCTOR
JESD-609 Code e1
Number of Functions 1
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -40 °C
Package Height 3.2 mm
Package Length 4.5 mm
Package Style SMT
Package Width 4 mm
Packing Method TR, EMBOSSED, 13 INCH
Rated Current-Max 0.11 A
Self Resonance Frequency 2.8 MHz
Shape/Size Description RECTANGULAR PACKAGE
Shielded NO
Surface Mount YES
Terminal Finish TIN SILVER COPPER
Terminal Placement DUAL ENDED
Terminal Shape ONE SURFACE
Test Frequency 0.001 MHz
Tolerance 10%

SDR0403-681KL Related Parts
