SC68376BACAB25 Information
SC68376BACAB25 by NXP Semiconductors is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for SC68376BACAB25
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
49AC5092
|
Newark | Mcu, 32Bit, Cpu32, 20.97Mhz, Qfp-160, Product Range:Cpu32 Family Sc68376 Series Microcontrollers, Architecture:Cpu32, No. Of Bits:32Bit, Cpu Speed:20.97Mhz, Program Memory Size:-, Ram Memory Size:4Kb, No. Of Pins:160Pins, Mcu Case Rohs Compliant: Yes |Nxp SC68376BACAB25 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$62.3600 / $75.4800 | Buy Now |
|
DISTI #
SC68376BACAB25-ND
|
DigiKey | IC MCU 32BIT ROMLESS 160QFP Min Qty: 120 Lead time: 18 Weeks Container: Tray | Limited Supply - Call |
|
$63.3916 | Buy Now |
|
DISTI #
SC68376BACAB25
|
Avnet Americas | 32BIT MCU, 8K ROM - Trays (Alt: SC68376BACAB25) RoHS: Compliant Min Qty: 120 Package Multiple: 120 Lead time: 18 Weeks, 0 Days Container: Tray | 0 |
|
$53.6377 / $55.4850 | Buy Now |
|
DISTI #
841-SC68376BACAB25
|
Mouser Electronics | 32-bit Microcontrollers - MCU 32BIT MCU 8K ROM RoHS: Compliant | 0 |
|
$63.4000 / $78.6500 | Order Now |
|
DISTI #
SC68376BACAB25
|
Avnet Silica | 32BIT MCU 8K ROM (Alt: SC68376BACAB25) RoHS: Compliant Min Qty: 24 Package Multiple: 24 Lead time: 20 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
SC68376BACAB25
|
EBV Elektronik | 32BIT MCU 8K ROM (Alt: SC68376BACAB25) RoHS: Compliant Min Qty: 24 Package Multiple: 24 Lead time: 20 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Flip Electronics | Stock | 9 |
|
RFQ |
Part Details for SC68376BACAB25
SC68376BACAB25 CAD Models
SC68376BACAB25 Part Data Attributes
|
|
SC68376BACAB25
NXP Semiconductors
Buy Now
Datasheet
|
Compare Parts:
SC68376BACAB25
NXP Semiconductors
32-BIT, MROM, 20.97MHz, MICROCONTROLLER, PQFP160
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | NXP SEMICONDUCTORS | |
| Package Description | 28 X 28 MM, 3.30 MM HEIGHT, 0.65 MM PITCH,HALOGEN FREE AND ROHS COMPLIANT, PLASTIC, QFP-160 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.31.00.01 | |
| Factory Lead Time | 18 Weeks | |
| Samacsys Manufacturer | NXP | |
| Has ADC | YES | |
| Address Bus Width | 24 | |
| Bit Size | 32 | |
| Boundary Scan | NO | |
| Clock Frequency-Max | 20.97 MHz | |
| DAC Channels | YES | |
| DMA Channels | NO | |
| External Data Bus Width | 16 | |
| JESD-30 Code | S-PQFP-G160 | |
| Length | 28 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of I/O Lines | 46 | |
| Number of Terminals | 160 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | QFP | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK | |
| Peak Reflow Temperature (Cel) | 245 | |
| Qualification Status | Not Qualified | |
| ROM (words) | 8192 | |
| ROM Programmability | MROM | |
| Seated Height-Max | 3.85 mm | |
| Speed | 20.97 MHz | |
| Supply Voltage-Max | 5.25 V | |
| Supply Voltage-Min | 4.75 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | HCMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 28 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER |
