SC-12-E035J Information
SC-12-E035J by KEMET Corporation is a Main Filter.
Mains Filters are under the broader part category of Filters.
A filter is an electronic circuit that selectively allows certain frequencies to pass while attenuating others. They are used to extract desired signals and remove noise. Read more about Filters on our Filters part category page.
Price & Stock for SC-12-E035J
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
66AH0470
|
Newark | Common Mode Filter, 0.35Mh, 12A Rohs Compliant: Yes |Kemet SC-12-E035J RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$1.6900 / $3.2200 | Buy Now |
|
DISTI #
399-SC-12-E035J-ND
|
DigiKey | CMC 350UH 12A 2LN TH Min Qty: 1 Lead time: 25 Weeks Container: Tray |
149 In Stock |
|
$1.3975 / $2.6700 | Buy Now |
|
DISTI #
80-SC-12-E035J
|
Mouser Electronics | Common Mode Chokes / Filters 250V 0.35mH 12A DCR=0.008Ohms RoHS: Compliant | 0 |
|
$1.3900 / $2.6700 | Order Now |
|
DISTI #
71823569
|
RS | AC Line Filter, CMC 0.35mH,12A, 0.008ohm Min Qty: 150 Package Multiple: 1 Container: Bulk | 0 |
|
$1.6430 / $1.6940 | RFQ |
|
DISTI #
SC-12-E035J
|
TME | Inductor: wire, THT, 350uH, 250VAC, 8mΩ, -25÷120°C, SC, 12A Min Qty: 1 | 0 |
|
$1.4900 / $2.3600 | RFQ |
|
DISTI #
SC-12-E035J
|
Avnet Abacus | (Alt: SC-12-E035J) RoHS: Compliant Min Qty: 150 Package Multiple: 30 Lead time: 26 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for SC-12-E035J
SC-12-E035J CAD Models
SC-12-E035J Part Data Attributes
|
|
SC-12-E035J
KEMET Corporation
Buy Now
Datasheet
|
Compare Parts:
SC-12-E035J
KEMET Corporation
SINGLE PHASE EMI FILTER,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | KEMET ELECTRONICS CORP | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | KEMET | |
| Approvals | UL | |
| Filter Type | SINGLE PHASE EMI FILTER | |
| Height | 25.5 mm | |
| High Pot | 500 V | |
| Insulation Resistance-Min | 100 MΩ | |
| Length | 25 mm | |
| Mounting Type | THROUGH HOLE MOUNT | |
| Operating Temperature-Max | 120 °C | |
| Operating Temperature-Min | -25 °C | |
| Packing Method | TRAY | |
| Rated Current | 12 A | |
| Rated Voltage | 250 V | |
| Width | 16 mm |
