S3M-E3/57T Information
S3M-E3/57T by Vishay Intertechnologies is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for S3M-E3/57T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
65K2755
|
Newark | Standard Diode, 3A, 1Kv, Do-214Ab, Repetitive Peak Reverse Voltage:1Kv, Average Forward Current:3A, Diode Configuration:Single, Forward Voltage Max:1.15V, Reverse Recovery Time:2.5Μs, Forward Surge Current:100A, Diode Case Style:Smd Rohs Compliant: Yes |Vishay S3M-E3/57T RoHS: Compliant Min Qty: 1700 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$0.2180 | Buy Now |
|
DISTI #
S3M-E3/57T
|
Avnet Americas | Standard Recovery Rectifier, 1 kV, 3 A, Single, 1.15 V, 2.5 ?s, 100 A, DO-214AB (SMC)2 Pins - Tape and Reel (Alt: S3M-E3/57T) RoHS: Compliant Min Qty: 850 Package Multiple: 850 Lead time: 5 Weeks, 0 Days Container: Reel | 306000 |
|
$0.0672 | Buy Now |
|
DISTI #
625-S3M-E3
|
Mouser Electronics | Rectifiers 3.0 Amp 1000 Volt RoHS: Compliant | 64993 |
|
$0.1100 / $0.4800 | Buy Now |
|
DISTI #
E02:0323_00192708
|
Arrow Electronics | Diode Switching 1KV 3A 2-Pin SMC T/R Min Qty: 850 Package Multiple: 850 Lead time: 5 Weeks Date Code: 2503 | Europe - 496400 |
|
$0.0982 / $0.1262 | Buy Now |
|
DISTI #
V36:1790_18773941
|
Arrow Electronics | Diode Switching 1KV 3A 2-Pin SMC T/R Min Qty: 1700 Package Multiple: 1700 Lead time: 5 Weeks Date Code: 2334 | Americas - 4250 |
|
$0.0682 | Buy Now |
|
DISTI #
E21:3489_00192708
|
Arrow Electronics | Diode Switching 1KV 3A 2-Pin SMC T/R Min Qty: 1 Package Multiple: 1 Lead time: 5 Weeks | Europe - 1134 |
|
$0.0955 / $0.4695 | Buy Now |
|
DISTI #
V72:2272_18773941
|
Arrow Electronics | Diode Switching 1KV 3A 2-Pin SMC T/R Min Qty: 1 Package Multiple: 1 Lead time: 5 Weeks Date Code: 2022 Container: Cut Strips | Americas - 223 |
|
$0.0999 / $0.4498 | Buy Now |
|
|
Future Electronics | S3J Series 3 A 1000 V Surface Mount Glass Passivated Rectifier - DO-214AB RoHS: Compliant pbFree: Yes Min Qty: 850 Package Multiple: 850 Lead time: 5 Weeks Container: Reel | 12750Reel |
|
$0.0779 / $0.0851 | Buy Now |
|
DISTI #
87689003
|
Verical | Diode Switching 1KV 3A 2-Pin SMC T/R Min Qty: 850 Package Multiple: 850 Date Code: 2503 | Americas - 496400 |
|
$0.1250 / $0.1443 | Buy Now |
|
DISTI #
67177147
|
Verical | Diode Switching 1KV 3A 2-Pin SMC T/R Min Qty: 326 Package Multiple: 1 Date Code: 2201 | Americas - 16518 |
|
$0.0965 / $0.1500 | Buy Now |
Part Details for S3M-E3/57T
S3M-E3/57T CAD Models
S3M-E3/57T Part Data Attributes
|
|
S3M-E3/57T
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
S3M-E3/57T
Vishay Intertechnologies
Rectifier Diode, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-214AB, SMC, 2 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | SMC, 2 PIN | |
| Reach Compliance Code | not_compliant | |
| Factory Lead Time | 5 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | FREE WHEELING DIODE, LOW LEAKAGE CURRENT | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1.15 V | |
| JEDEC-95 Code | DO-214AB | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 100 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Current-Max | 3 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 1000 V | |
| Reverse Recovery Time-Max | 2.5 µs | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | C BEND | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Alternate Parts for S3M-E3/57T
This table gives cross-reference parts and alternative options found for S3M-E3/57T. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of S3M-E3/57T, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| S3M | Daco Semiconductor Co Ltd | $0.0744 | Rectifier Diode, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-214AB, SMC, 2 PIN | S3M-E3/57T vs S3M |
| S3M-E3/9AT | Vishay Intertechnologies | $0.2122 | Rectifier Diode, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-214AB, SMC, 2 PIN | S3M-E3/57T vs S3M-E3/9AT |
| S3K-TP | Micro Commercial Components | Check for Price | Rectifier Diode, 1 Phase, 1 Element, 3A, 800V V(RRM), Silicon, DO-214AB, ROHS COMPLIANT, PLASTIC, SMCJ, 2 PIN | S3M-E3/57T vs S3K-TP |
| S3M-TR7G | Taiwan Semiconductor | Check for Price | Rectifier Diode, | S3M-E3/57T vs S3M-TR7G |
| S3M | Surge Components Inc | Check for Price | Rectifier Diode, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-214AB, SMC, 2 PIN | S3M-E3/57T vs S3M |
| S3MR6G | Taiwan Semiconductor | Check for Price | Rectifier Diode, Schottky, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-214AB, GREEN, PLASTIC, SMC, 2 PIN | S3M-E3/57T vs S3MR6G |
| S3M | Lision Technology Inc | Check for Price | Rectifier Diode, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-214AB, PLASTIC, SMC, 2 PIN | S3M-E3/57T vs S3M |
| S3M | Diodes Incorporated | Check for Price | Rectifier Diode, 1 Element, 2.5A, 1000V V(RRM) | S3M-E3/57T vs S3M |
