S1GB-13-F Information
S1GB-13-F by Diodes Incorporated is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for S1GB-13-F
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69AH2908
|
Newark | Rectifier, Single, 400V, 1A, Smb Rohs Compliant: Yes |Diodes Inc. S1GB-13-F RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2655 |
|
$0.0480 / $0.2500 | Buy Now |
|
DISTI #
31-S1GB-13-FCT-ND
|
DigiKey | DIODE STANDARD 400V 1A SMB Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
862138 In Stock |
|
$0.0300 / $0.1800 | Buy Now |
|
DISTI #
S1GB-13-F
|
Avnet Americas | Standard Recovery Rectifier, 400 V, 1 A, Single, 1.1 V, 1.8 us, 30 A, DO-214AA (SMB), 2 Pins - Tape and Reel (Alt: S1GB-13-F) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks, 0 Days Container: Reel | 570004449000 Factory Stock |
|
$0.0244 / $0.0260 | Buy Now |
|
DISTI #
S1GB-13-F
|
Avnet Americas | Standard Recovery Rectifier, 400 V, 1 A, Single, 1.1 V, 1.8 us, 30 A, DO-214AA (SMB), 2 Pins - Tape and Reel (Alt: S1GB-13-F) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 111 Weeks, 0 Days Container: Reel | 4449000 Factory Stock |
|
$0.0276 / $0.0295 | Buy Now |
|
DISTI #
621-S1GB-F
|
Mouser Electronics | Rectifiers 400V 1A RoHS: Compliant | 359113 |
|
$0.0320 / $0.1800 | Buy Now |
|
DISTI #
V79:2366_28369294
|
Arrow Electronics | Diode Switching 400V 1A 2-Pin SMB T/R Min Qty: 3759 Package Multiple: 1 Date Code: 2209 | Americas - 11499810 |
|
$0.0266 | Buy Now |
|
DISTI #
V36:1790_06703643
|
Arrow Electronics | Diode Switching 400V 1A 2-Pin SMB T/R Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks Date Code: 2218 | Americas - 42000 |
|
$0.0282 / $0.0307 | Buy Now |
|
DISTI #
E02:0323_01115333
|
Arrow Electronics | Diode Switching 400V 1A 2-Pin SMB T/R Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks Date Code: 2402 | Europe - 3000 |
|
$0.0306 / $0.0311 | Buy Now |
|
DISTI #
V72:2272_06703643
|
Arrow Electronics | Diode Switching 400V 1A 2-Pin SMB T/R Min Qty: 375 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2228 Container: Cut Strips | Americas - 375 |
|
$0.1000 | Buy Now |
|
|
Future Electronics | S1G Series 400 V 1 A Surface Mount Glass Passivated Rectifier - DO-214AA RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks Container: Reel | 234000Reel |
|
$0.0285 / $0.0307 | Buy Now |
Part Details for S1GB-13-F
S1GB-13-F CAD Models
S1GB-13-F Part Data Attributes
|
|
S1GB-13-F
Diodes Incorporated
Buy Now
Datasheet
|
Compare Parts:
S1GB-13-F
Diodes Incorporated
Rectifier Diode, 1 Element, 1A, 400V V(RRM), Silicon, GREEN, PLASTIC, SMB, 2 PIN
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | DIODES INC | |
| Package Description | SMB, 2 PIN | |
| Pin Count | 2 | |
| Manufacturer Package Code | SMB | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.80 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Diodes Incorporated | |
| Additional Feature | HIGH RELIABILITY | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1.1 V | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 30 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -65 °C | |
| Output Current-Max | 1 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 400 V | |
| Reverse Recovery Time-Max | 3 µs | |
| Surface Mount | YES | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | C BEND | |
| Terminal Position | DUAL |
