S103M47Z5UN63L0R Information
S103M47Z5UN63L0R by Vishay Intertechnologies is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for S103M47Z5UN63L0R
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
83K9283
|
Newark | Ceramic Capacitor 0.01Uf 1000V, Z5U, 20%, Radial, Capacitance:0.01Μf, Voltage(Dc):1Kv, Capacitance Tolerance:± 20%, Dielectric Characteristic:Z5U, Lead Spacing:10Mm, Capacitor Terminals:Radial Leaded, Product Range:S Series Rohs Compliant: Yes |Vishay S103M47Z5UN63L0R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 8854 |
|
$0.0950 / $0.1210 | Buy Now |
|
DISTI #
82AC0178
|
Newark | S 1Kv 10Nf 20% Z5U Bulk E3 Rohs Compliant: Yes |Vishay S103M47Z5UN63L0R RoHS: Compliant Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Bulk | 8000 |
|
$0.1320 | Buy Now |
|
DISTI #
S103M47Z5UN63L0R
|
Avnet Americas | Ceramic Disc Capacitor, 0.01 ?F, 1 kV, ? 20%, Z5U, 10 mm, Radial Leaded - Bulk (Alt: S103M47Z5UN63L0R) RoHS: Compliant Min Qty: 1000 Package Multiple: 1 Lead time: 8 Weeks, 0 Days Container: Bulk | 8000 |
|
$0.0780 / $0.0892 | Buy Now |
|
DISTI #
83K9283
|
Avnet Americas | Ceramic Disc Capacitor, 0.01 ?F, 1 kV, ? 20%, Z5U, 10 mm, Radial Leaded - Bulk (Alt: 83K9283) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks, 3 Days Container: Bulk | 8854 Partner Stock |
|
$0.1240 / $0.3900 | Buy Now |
|
DISTI #
594-S103M47Z5UN63L0R
|
Mouser Electronics | Ceramic Disc Capacitors .375LS .01UF 1KV 20% RoHS: Compliant | 17317 |
|
$0.0940 / $0.4100 | Buy Now |
|
DISTI #
V36:1790_07470745
|
Arrow Electronics | Cap Ceramic Single 0.01uF 1000V Z5U 20% (12 X 4mm) Radial Disc 10mm 125°C Bulk RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 8 Weeks Date Code: 2419 | Americas - 8867 |
|
$0.0808 / $0.3612 | Buy Now |
|
DISTI #
E02:0323_00518457
|
Arrow Electronics | Cap Ceramic Single 0.01uF 1000V Z5U 20% (12 X 4mm) Radial Disc 10mm 125°C Bulk RoHS: Compliant Min Qty: 4000 Package Multiple: 1000 Lead time: 8 Weeks | Europe - 4000 |
|
$0.0718 | Buy Now |
|
|
Future Electronics | S Series Ø 12 x 4 mm 0.01 uF 1000 V 20% Z5U Radial Ceramic Disc Capacitor RoHS: Compliant pbFree: Yes Min Qty: 1000 Package Multiple: 1000 Lead time: 8 Weeks Container: Bag | 9000Bag |
|
$0.1290 / $0.1360 | Buy Now |
|
DISTI #
84359309
|
Verical | Cap Ceramic Single 0.01uF 1000V Z5U 20% (12 X 4mm) Radial Disc 10mm 125°C Bulk RoHS: Compliant Min Qty: 73 Package Multiple: 1 Date Code: 2419 | Americas - 8867 |
|
$0.0808 / $0.2053 | Buy Now |
|
DISTI #
22289607
|
Verical | Cap Ceramic Single 0.01uF 1000V Z5U 20% (12 X 4mm) Radial Disc 10mm 125°C Bulk RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 | Americas - 4000 |
|
$0.0716 | Buy Now |
Part Details for S103M47Z5UN63L0R
S103M47Z5UN63L0R CAD Models
S103M47Z5UN63L0R Part Data Attributes
|
|
S103M47Z5UN63L0R
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
S103M47Z5UN63L0R
Vishay Intertechnologies
Ceramic Capacitor, Ceramic, 1000V, 20% +Tol, 20% -Tol, Z5U, -56/+22% TC, 0.01uF, Through Hole Mount, RADIAL LEADED
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | RADIAL LEADED | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.23.00.60 | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | STANDARD: IEC60384-9 | |
| Capacitance | 0.01 µF | |
| Capacitor Type | CERAMIC CAPACITOR | |
| Dielectric Material | CERAMIC | |
| Height | 12 mm | |
| JESD-609 Code | e3 | |
| Length | 12 mm | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Multilayer | No | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -30 °C | |
| Package Shape | DISK PACKAGE | |
| Package Style | Radial | |
| Packing Method | Bulk | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 1000 V | |
| Reference Standard | IEC60384-8 | |
| Surface Mount | NO | |
| Temperature Characteristics Code | Z5U | |
| Temperature Coefficient | -56/+22% ppm/°C | |
| Terminal Finish | Tin (Sn) - hot dipped | |
| Terminal Pitch | 10 mm | |
| Terminal Shape | WIRE | |
| Width | 4 mm |
