RW2-2415D/H3/B Information
RW2-2415D/H3/B by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for RW2-2415D/H3/B
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
945-3390-ND
|
DigiKey | DC DC CONVERTER +/-15V 2W Min Qty: 1 Lead time: 17 Weeks Container: Tube |
105 In Stock |
|
$18.0001 / $23.2000 | Buy Now |
|
DISTI #
919-RW2-2415DH3B
|
Mouser Electronics | Isolated DC/DC Converters - Through Hole 2W DC/DC MIN 3kV REG 2:1 18-36in +/-15ou RoHS: Compliant | 0 |
|
$18.0000 / $22.8000 | Order Now |
|
DISTI #
10013975
|
RECOM Power | 2W DC/DC-Converter 'ECONOLINE' DIP16 Mini 3kV reg 2:1 RoHS: Compliant | 105 |
|
RFQ | |
|
DISTI #
72185804
|
RS | DC-DC Converter, DIP16 Mini 3kV reg , Dual, 2W, +/-15V, +/-67mA, RW2 Series Min Qty: 22 Package Multiple: 1 Lead time: 17 Weeks, 0 Days Container: Bulk | 0 |
|
$23.6900 / $25.4800 | RFQ |
|
|
Onlinecomponents.com | RoHS: Compliant | 0 |
|
$17.7300 / $23.2800 | Buy Now |
|
DISTI #
RW2-2415D/H3/B
|
TME | Converter: DC/DC, 2W, Uin: 18÷36VDC, Uout: 15VDC, Uout2: -15VDC, RW2 Min Qty: 1 | 0 |
|
$18.5600 / $21.7000 | RFQ |
|
DISTI #
000000000006067322
|
Sager | Isolated DC/DC Converters - Through Hole 2W DC/DC MIN 3kV REG 2:1 18-36in +/-15ou Min Qty: 1 | 0 |
|
$19.2700 / $22.4800 | Buy Now |
Part Details for RW2-2415D/H3/B
RW2-2415D/H3/B CAD Models
RW2-2415D/H3/B Part Data Attributes
|
|
RW2-2415D/H3/B
RECOM Power GmbH
Buy Now
Datasheet
|
Compare Parts:
RW2-2415D/H3/B
RECOM Power GmbH
DC-DC Regulated Power Supply Module, 2 Output, 1W, Hybrid, ROHS COMPLIANT, MINI DIP-16/6
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | RECOM POWER GMBH | |
| Part Package Code | DIP | |
| Package Description | Module-6 | |
| Pin Count | 16/6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | RECOM Power | |
| Analog IC - Other Type | DC-DC REGULATED POWER SUPPLY MODULE | |
| Approvals | EN, IEC | |
| Control Mode | VOLTAGE-MODE | |
| Efficiency (Main Output) | 83% | |
| Input Voltage-Max | 36 V | |
| Input Voltage-Min | 18 V | |
| Input Voltage-Nom | 24 V | |
| JESD-30 Code | R-PDMA-P6 | |
| Length | 22.1 mm | |
| Line Regulation-Max | 0.5% | |
| Number of Functions | 1 | |
| Number of Outputs | 2 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.067 A | |
| Output Voltage-Max | 15.3 V | |
| Output Voltage-Min | 14.7 V | |
| Output Voltage-Nom | 15 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | DMA | |
| Package Shape | RECTANGULAR | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | 255 | |
| Protections | OVER CURRENT | |
| Ripple Voltage (Main Out) | 0.17675 Vrms | |
| Seated Height-Max | 9 mm | |
| Surface Mount | NO | |
| Technology | HYBRID | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | PIN/PEG | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 5 | |
| Total Power Output-Max | 2 W | |
| Trim/Adjustable Output | NO | |
| Width | 12.55 mm |
