RUR020N02TL Information
RUR020N02TL by ROHM Semiconductor is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for RUR020N02TL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
78AC6457
|
Newark | Mosfet, N-Ch, 20V, 2A, Sot-346T, Transistor Polarity:N Channel, Continuous Drain Current Id:2A, Drain Source Voltage Vds:20V, On Resistance Rds(On):0.075Ohm, Rds(On) Test Voltage Vgs:4.5V, Threshold Voltage Vgs:1V, Power Dissipation Rohs Compliant: Yes |Rohm RUR020N02TL RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 4440 |
|
$0.1920 / $0.5100 | Buy Now |
|
DISTI #
RUR020N02TLCT-ND
|
DigiKey | MOSFET N-CH 20V 2A TSMT3 Min Qty: 1 Lead time: 21 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
7767 In Stock |
|
$0.1438 / $0.7900 | Buy Now |
|
DISTI #
755-RUR020N02TL
|
Mouser Electronics | MOSFETs SW MOSFET MID PWR N-CH 20V 2A RoHS: Compliant | 3954 |
|
$0.1430 / $0.7800 | Buy Now |
|
DISTI #
84942420
|
Verical | Trans MOSFET N-CH Si 20V 2A 3-Pin TSMT T/R RoHS: Compliant Min Qty: 274 Package Multiple: 1 Date Code: 2226 | Americas - 23410 |
|
$0.2800 / $0.3430 | Buy Now |
|
DISTI #
66429809
|
Verical | Trans MOSFET N-CH Si 20V 2A 3-Pin TSMT T/R RoHS: Compliant Min Qty: 371 Package Multiple: 1 Date Code: 2301 | Americas - 19416 |
|
$0.1818 / $0.2116 | Buy Now |
|
DISTI #
62337753
|
Verical | Trans MOSFET N-CH Si 20V 2A 3-Pin TSMT T/R RoHS: Compliant Min Qty: 371 Package Multiple: 1 Date Code: 2201 | Americas - 8830 |
|
$0.1863 / $0.2116 | Buy Now |
|
DISTI #
63493175
|
Verical | Trans MOSFET N-CH Si 20V 2A 3-Pin TSMT T/R RoHS: Compliant Min Qty: 371 Package Multiple: 1 Date Code: 2201 | Americas - 533 |
|
$0.2040 / $0.2116 | Buy Now |
|
|
Bristol Electronics | 1425 |
|
RFQ | ||
|
|
Quest Components | 23023 |
|
$0.1815 / $0.6050 | Buy Now | |
|
|
Quest Components | 1140 |
|
$0.2808 / $0.9360 | Buy Now |
Part Details for RUR020N02TL
RUR020N02TL CAD Models
RUR020N02TL Part Data Attributes
|
|
RUR020N02TL
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
RUR020N02TL
ROHM Semiconductor
Small Signal Field-Effect Transistor, 2A I(D), 20V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TSMT3, 3 PIN
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Package Description | TSMT3, 3 PIN | |
| Pin Count | 3 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 21 Weeks | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 20 V | |
| Drain Current-Max (ID) | 2 A | |
| Drain-source On Resistance-Max | 0.105 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e1 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 1 W | |
| Qualification Status | Not Qualified | |
| Surface Mount | YES | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
