RSB6.8GT2R Information
RSB6.8GT2R by ROHM Semiconductor is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for RSB6.8GT2R
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
70521873
|
RS | ROHM RSB6.8GT2R, ESD Protection Diode, 2-Pin VMD Min Qty: 5 Package Multiple: 1 Container: Bulk | 0 |
|
$0.1390 / $0.1740 | RFQ |
|
|
Vyrian | Diodes | 1130 |
|
RFQ |
Part Details for RSB6.8GT2R
RSB6.8GT2R CAD Models
RSB6.8GT2R Part Data Attributes
|
|
RSB6.8GT2R
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
RSB6.8GT2R
ROHM Semiconductor
Trans Voltage Suppressor Diode, Bidirectional,
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH RELIABILITY | |
| Breakdown Voltage-Max | 7.82 V | |
| Breakdown Voltage-Min | 5.78 V | |
| Breakdown Voltage-Nom | 6.8 V | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JESD-30 Code | R-PDSO-F2 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Peak Rev Power Dis-Max | 10 W | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | BIDIRECTIONAL | |
| Power Dissipation-Max | 0.1 W | |
| Rep Pk Reverse Voltage-Max | 3.5 V | |
| Reverse Current-Max | 0.5 µA | |
| Reverse Test Voltage | 3.5 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
