RS1G201ATTB1 Information
RS1G201ATTB1 by ROHM Semiconductor is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for RS1G201ATTB1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
91AH8988
|
Newark | Mosfet, P-Ch, 40V, 78A, Hsop Rohs Compliant: Yes |Rohm RS1G201ATTB1 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2500 |
|
$1.6000 | Buy Now |
|
DISTI #
86AK6128
|
Newark | Mosfet, P-Ch, 40V, 78A, Hsop Rohs Compliant: Yes |Rohm RS1G201ATTB1 RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 1 Container: Reel | 0 |
|
$1.2400 | Buy Now |
|
DISTI #
846-RS1G201ATTB1CT-ND
|
DigiKey | MOSFET P-CH 40V 20A/78A 8HSOP Min Qty: 1 Lead time: 21 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
3711 In Stock |
|
$1.2054 / $2.1200 | Buy Now |
|
DISTI #
755-RS1G201ATTB1
|
Mouser Electronics | MOSFETs HSOP8 40V 78A P CHAN RoHS: Compliant | 8554 |
|
$1.1500 / $1.9400 | Buy Now |
|
|
Future Electronics | RoHS: Compliant pbFree: Yes Min Qty: 2500 Package Multiple: 2500 Lead time: 18 Weeks Container: Reel | 5000Reel |
|
$1.3400 | Buy Now |
|
|
Future Electronics | -40V, -78A, 5.2MOHM, P-CHANNEL, HSOP8 RoHS: Compliant pbFree: Yes Min Qty: 2500 Package Multiple: 2500 Lead time: 18 Weeks Container: Reel | 0Reel |
|
$1.3400 | Buy Now |
|
DISTI #
87600880
|
Verical | Trans MOSFET P-CH 40V 20A 8-Pin HSOP EP T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Date Code: 2310 | Americas - 2500 |
|
$2.1102 | Buy Now |
|
DISTI #
84342399
|
Verical | Trans MOSFET P-CH 40V 20A 8-Pin HSOP EP T/R RoHS: Compliant Min Qty: 49 Package Multiple: 1 Date Code: 2201 | Americas - 100 |
|
$1.4566 / $1.5674 | Buy Now |
|
DISTI #
RS1G201ATTB1
|
TTI | MOSFETs HSOP8 40V 78A P CHAN RoHS: Compliant pbFree: Pb-Free Min Qty: 2500 Package Multiple: 2500 Container: Reel | Americas - 0 |
|
$1.1300 | Buy Now |
|
|
Future Electronics | -40V, -78A, 5.2MOHM, P-CHANNEL, HSOP8 Min Qty: 2500 Package Multiple: 2500 |
5000 null |
|
$1.3400 | Buy Now |
Part Details for RS1G201ATTB1
RS1G201ATTB1 CAD Models
RS1G201ATTB1 Part Data Attributes
|
|
RS1G201ATTB1
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
RS1G201ATTB1
ROHM Semiconductor
Power Field-Effect Transistor, 20A I(D), 40V, 0.0065ohm, 1-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 21 Weeks | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Avalanche Energy Rating (Eas) | 31 mJ | |
| Case Connection | DRAIN | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 40 V | |
| Drain Current-Max (ID) | 20 A | |
| Drain-source On Resistance-Max | 0.0065 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 590 pF | |
| JESD-30 Code | R-PDSO-F5 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 5 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | P-CHANNEL | |
| Power Dissipation-Max (Abs) | 40 W | |
| Pulsed Drain Current-Max (IDM) | 80 A | |
| Surface Mount | YES | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
