RPR-220PC30N Information
RPR-220PC30N by ROHM Semiconductor is a Linear Position Sensor.
Linear Position Sensors are under the broader part category of Sensors/Transducers.
Sensors and transducers detect and measure physical quantities like temperature, pressure, and force, converting them into electrical signals for various applications. Read more about Sensors/Transducers on our Sensors/Transducers part category page.
Price & Stock for RPR-220PC30N
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
846-1014-ND
|
DigiKey | REFL OPT SENS 0.236" 4DIP Min Qty: 1 Lead time: 12 Weeks Container: Bulk |
176 In Stock |
|
$3.9852 / $5.2700 | Buy Now |
|
DISTI #
53817506
|
Verical | Photointerrupter Reflective Phototransistor 4-Pin Tube RoHS: Compliant Min Qty: 20 Package Multiple: 1 Date Code: 2015 | Americas - 12404 |
|
$2.7000 / $3.8100 | Buy Now |
|
DISTI #
36533189
|
Verical | Photointerrupter Reflective Phototransistor 4-Pin Tube RoHS: Compliant Min Qty: 31 Package Multiple: 1 Date Code: 1901 | Americas - 690 |
|
$4.0513 / $4.2105 | Buy Now |
|
|
Quest Components | 552 |
|
$2.5757 / $4.6830 | Buy Now | |
|
|
Ameya Holding Limited | RPR-220PC30N Series 470 nm 30 mA Reflective Type Photosensor Min Qty: 1 | 60-Authorized Distributor |
|
$2.1709 / $5.5272 | Buy Now RFQ |
|
DISTI #
RPR-220PC30N
|
Avnet Silica | Photointerrupter Reflective Phototransistor 4Pin (Alt: RPR-220PC30N) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 143 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
RPR-220PC30N
|
Chip One Stop | Opto-electronics RoHS: Compliant pbFree: Yes Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Tube | 12404 |
|
$2.6500 / $3.8100 | Buy Now |
|
|
Vyrian | Sensors & Transducers | 7955 |
|
RFQ |
Part Details for RPR-220PC30N
RPR-220PC30N CAD Models
RPR-220PC30N Part Data Attributes
|
|
RPR-220PC30N
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
RPR-220PC30N
ROHM Semiconductor
Diffuse Photoelectric Sensor, 10mm Max, 0.08-0.80mA, 1-Channel, Rectangular, Through Hole Mount,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH SENSITIVITY, DARK CURRENT 10 MICRO AMP | |
| Body Breadth | 4.9 mm | |
| Body Height | 6.5 mm | |
| Body Length or Diameter | 6.4 mm | |
| Measurement Range-Max (mm) | 10 mm | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Number of Channels | 1 | |
| Operating Current-Max | 25 mA | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -25 °C | |
| Output Circuit Type | Transistor | |
| Output Current-Max | 0.8 mA | |
| Output Range | 0.08-0.80mA | |
| Output Type | ANALOG CURRENT | |
| Output Voltage-Max | 30 V | |
| Package Shape/Style | RECTANGULAR | |
| Response Time | 10 µs | |
| Sensors/Transducers Type | LINEAR POSITION SENSOR,PHOTOELECTRIC,DIFFUSE | |
| Supply Voltage-Max | 3.8 V | |
| Surface Mount | NO | |
| Termination Type | SOLDER | |
| VCEsat-Max | 0.3 V |
