3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for RP40-4805SGW/N-HC by RECOM Power GmbH
Results Overview of RP40-4805SGW/N-HC by RECOM Power GmbH
- Distributor Offerings: (4 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
RP40-4805SGW/N-HC Information
RP40-4805SGW/N-HC by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for RP40-4805SGW/N-HC
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
RP40-4805SGW/N-HC-ND
|
DigiKey | DC DC CONVERTER 5V 40W Min Qty: 12 Lead time: 10 Weeks Container: Tube | Temporarily Out of Stock |
|
$116.3667 | Buy Now |
|
DISTI #
30002072
|
RECOM Power | 40W DC/DC-Converter 'POWERLINE' 2"x2" 1.6kV reg 4:1 RoHS: Compliant | 0 |
|
$116.3700 | RFQ |
|
|
Onlinecomponents.com | RoHS: Compliant | 0 |
|
$102.2700 / $149.0800 | Buy Now |
|
DISTI #
000000000006065313
|
Sager | Isolated DC/DC Converters - Through Hole 40W DC/DC 1.6kV REG 4:1 18-75Vin 5Vout Min Qty: 1 | 0 |
|
$95.5800 / $124.2300 | Buy Now |
Part Details for RP40-4805SGW/N-HC
RP40-4805SGW/N-HC CAD Models
RP40-4805SGW/N-HC Part Data Attributes
|
|
RP40-4805SGW/N-HC
RECOM Power GmbH
Buy Now
Datasheet
|
Compare Parts:
RP40-4805SGW/N-HC
RECOM Power GmbH
DC-DC Regulated Power Supply Module, 1 Output, 40W, Hybrid, ROHS COMPLIANT, PACKAGE-8
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | RECOM POWER GMBH | |
| Part Package Code | MODULE | |
| Package Description | , | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | RECOM Power | |
| Additional Feature | HGT NOM | |
| Analog IC - Other Type | DC-DC REGULATED POWER SUPPLY MODULE | |
| Input Voltage-Max | 75 V | |
| Input Voltage-Min | 18 V | |
| Input Voltage-Nom | 48 V | |
| JESD-30 Code | S-PSMA-T8 | |
| Length | 51.3 mm | |
| Load Regulation-Max | 0.5% | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 55 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Voltage-Max | 5.5 V | |
| Output Voltage-Min | 4.5 V | |
| Output Voltage-Nom | 5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SMA | |
| Package Shape | SQUARE | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | 255 | |
| Seated Height-Max | 10.2 mm | |
| Surface Mount | NO | |
| Technology | HYBRID | |
| Temperature Grade | OTHER | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | 5 | |
| Total Power Output-Max | 40 W | |
| Trim/Adjustable Output | YES | |
| Width | 51.3 mm |
