3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for RP15-4815DF by RECOM Power GmbH
Results Overview of RP15-4815DF by RECOM Power GmbH
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
RP15-4815DF Information
RP15-4815DF by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for RP15-4815DF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
93X2818
|
Newark | 15W Dc/Dc-Converter Powerline 2"x1" 1.6Kv Reg 2:1 Rohs Compliant: Yes |Recom Power RP15-4815DF RoHS: Compliant Min Qty: 9 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$69.2100 / $79.7300 | Buy Now |
|
DISTI #
1486-RP15-4815DF-CHP
|
DigiKey | DC DC CONVERTER +/-15V 15W Min Qty: 9 Lead time: 10 Weeks Container: Tube, Tube |
9 In Stock |
|
$50.5878 / $64.4711 | Buy Now |
|
DISTI #
919-RP15-4815DF
|
Mouser Electronics | Isolated DC/DC Converters - Through Hole 15W DC/DC 1.6kV REG 2:1 36-75in +/-15out RoHS: Compliant | 0 |
|
$55.1800 / $66.4200 | Order Now |
|
DISTI #
30000374
|
RECOM Power | 15W DC/DC-Converter 'POWERLINE' 2"x1" 1.6kV reg 2:1 RoHS: Compliant | 9 |
|
RFQ | |
|
|
Onlinecomponents.com | RoHS: Compliant | 0 |
|
$51.8800 / $69.7800 | Buy Now |
|
DISTI #
000000000006064348
|
Sager | Isolated DC/DC Converters - Through Hole 15W DC/DC 1.6kV REG 2:1 36-75in +/-15out Min Qty: 1 | 0 |
|
$51.8800 / $67.4400 | Buy Now |
Part Details for RP15-4815DF
RP15-4815DF CAD Models
RP15-4815DF Part Data Attributes
|
|
RP15-4815DF
RECOM Power GmbH
Buy Now
Datasheet
|
Compare Parts:
RP15-4815DF
RECOM Power GmbH
DC-DC Regulated Power Supply Module, 2 Output, 15W, Hybrid, PACKAGE-6/5
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | RECOM POWER GMBH | |
| Package Description | PACKAGE-6/5 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | RECOM Power | |
| Additional Feature | ALSO -15V OUTPUT AVAILABLE | |
| Analog IC - Other Type | DC-DC REGULATED POWER SUPPLY MODULE | |
| Input Voltage-Max | 75 V | |
| Input Voltage-Min | 36 V | |
| Input Voltage-Nom | 48 V | |
| JESD-30 Code | R-XDMA-P5 | |
| JESD-609 Code | e3 | |
| Length | 50.8 mm | |
| Number of Functions | 1 | |
| Number of Outputs | 2 | |
| Number of Terminals | 5 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.5 A | |
| Output Voltage-Max | 15.15 V | |
| Output Voltage-Min | 14.85 V | |
| Output Voltage-Nom | 15 V | |
| Package Body Material | UNSPECIFIED | |
| Package Code | DMA | |
| Package Equivalence Code | MODULE,6LEAD,0.8 | |
| Package Shape | RECTANGULAR | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | 255 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 10.7 mm | |
| Surface Mount | NO | |
| Technology | HYBRID | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | PIN/PEG | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 5 | |
| Total Power Output-Max | 15 W | |
| Trim/Adjustable Output | NO | |
| Width | 25.4 mm |
