RMCF0603FT470K Information
RMCF0603FT470K by SEI Stackpole Electronics Inc is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for RMCF0603FT470K
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
RMCF0603FT470KCT-ND
|
DigiKey | RES 470K OHM 1% 1/10W 0603 Min Qty: 1 Lead time: 17 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
626957 In Stock |
|
$0.0019 / $0.1000 | Buy Now |
|
DISTI #
RMCF0603FT470K
|
Avnet Americas | Res Thick Film 0603 470K Ohm 1% 1/10W ?100ppm/?C Molded SMD SMD Paper T/R - Tape and Reel (Alt: RMCF0603FT470K) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 17 Weeks, 0 Days Container: Reel | 5000340000 Factory Stock |
|
$0.0019 | Buy Now |
|
DISTI #
RMCF0603FT470K
|
Avnet Americas | Res Thick Film 0603 470K Ohm 1% 1/10W ?100ppm/?C Molded SMD SMD Paper T/R - Tape and Reel (Alt: RMCF0603FT470K) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 14 Weeks, 0 Days Container: Reel | 340000 Factory Stock |
|
$0.0018 / $0.0019 | Buy Now |
|
DISTI #
708-RMCF0603FT470K
|
Mouser Electronics | Thick Film Resistors - SMD 470KOhms 0603 0.1W 1% Std Power AEC-Q200 RoHS: Compliant | 45027 |
|
$0.0020 / $0.1000 | Buy Now |
|
DISTI #
V36:1790_07142284
|
Arrow Electronics | Res Thick Film 0603 470K Ohm 1% 0.1W(1/10W) ±100ppm/°C Pad SMD T/R Automotive AEC-Q200 Min Qty: 50000 Package Multiple: 5000 Lead time: 17 Weeks Date Code: 2243 | Americas - 75000 |
|
$0.0018 | Buy Now |
|
|
Future Electronics | RMCF Series 0603 470 kOhm ±1% 0.1 W ±100 ppm/°C SMT Thick Film Chip Resistor RoHS: Compliant pbFree: Yes Min Qty: 5000 Package Multiple: 5000 Lead time: 17 Weeks Container: Reel | 20000Reel |
|
$0.0017 / $0.0020 | Buy Now |
|
|
Onlinecomponents.com | Thick Film Resistor - 470 kohm ±1% - 0.1W - SMD 0603 - Tape&Reel RoHS: Compliant |
135000 In Stock 340000 Factory Stock |
|
$0.0021 / $0.0026 | Buy Now |
|
DISTI #
66955400
|
Verical | Res Thick Film 0603 470K Ohm 1% 0.1W(1/10W) ±100ppm/°C Pad SMD T/R Automotive AEC-Q200 Min Qty: 15000 Package Multiple: 5000 | Americas - 345000 |
|
$0.0069 / $0.0085 | Buy Now |
|
DISTI #
61252269
|
Verical | Res Thick Film 0603 470K Ohm 1% 0.1W(1/10W) ±100ppm/°C Pad SMD T/R Automotive AEC-Q200 Min Qty: 25000 Package Multiple: 5000 Date Code: 2124 | Americas - 135000 |
|
$0.0025 / $0.0028 | Buy Now |
|
DISTI #
78406998
|
Verical | Res Thick Film 0603 470K Ohm 1% 0.1W(1/10W) ±100ppm/°C Pad SMD T/R Automotive AEC-Q200 Min Qty: 50000 Package Multiple: 5000 Date Code: 2243 | Americas - 75000 |
|
$0.0021 / $0.0022 | Buy Now |
Part Details for RMCF0603FT470K
RMCF0603FT470K CAD Models
RMCF0603FT470K Part Data Attributes
|
|
RMCF0603FT470K
SEI Stackpole Electronics Inc
Buy Now
Datasheet
|
Compare Parts:
RMCF0603FT470K
SEI Stackpole Electronics Inc
Fixed Resistor, Metal Glaze/thick Film, 0.1W, 470000ohm, 75V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0603, CHIP
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STACKPOLE ELECTRONICS INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.30 | |
| Factory Lead Time | 17 Weeks | |
| Samacsys Manufacturer | Stackpole Electronics, Inc. | |
| Construction | Rectangular | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 155 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Height | 0.45 mm | |
| Package Length | 1.55 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 0.8 mm | |
| Packing Method | TR, Paper, 7 Inch | |
| Rated Power Dissipation (P) | 0.1 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 470000 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 0603 | |
| Surface Mount | YES | |
| Technology | METAL GLAZE/THICK FILM | |
| Temperature Coefficient | 100 ppm/°C | |
| Terminal Finish | MATTE TIN OVER NICKEL | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 1% | |
| Working Voltage | 75 V |
RMCF0603FT470K Frequently Asked Questions (FAQ)
-
The recommended land pattern for the RMCF0603FT470K is a rectangular pad with a size of 0.8mm x 1.2mm, with a non-solder mask defined (NSMD) pad shape.
-
Handle the component by the body, avoiding touching the terminations. Use anti-static wrist straps and mats to prevent electrostatic discharge (ESD) damage.
-
The maximum allowable voltage derating for the RMCF0603FT470K is 50% of the rated voltage, but it's recommended to consult the datasheet and application notes for specific derating guidelines.
-
The RMCF0603FT470K is rated for operation up to 125°C, but it's recommended to derate the component according to the temperature coefficient and consult the datasheet for specific guidelines.
-
The correct orientation of the RMCF0603FT470K is indicated by the marking on the component, which should face upwards during assembly.
