Resistors / Metal Glaze/Thick Film Resistors / RMCF0402JT13K0
Datasheets
RMCF0402JT13K0 by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 0.063W, 13000ohm, 50V, 5% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP

Part Details for RMCF0402JT13K0 by SEI Stackpole Electronics Inc

Results Overview of RMCF0402JT13K0 by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCF0402JT13K0 Information

RMCF0402JT13K0 by SEI Stackpole Electronics Inc is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCF0402JT13K0

Part # Distributor Description Stock Price Buy
DISTI # 738-RMCF0402JT13K0CT-ND
DigiKey RES 13K OHM 5% 1/16W 0402 Min Qty: 1 Lead time: 17 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) 14
In Stock
  • 1 $0.1000
  • 10 $0.0170
  • 50 $0.0094
  • 100 $0.0074
  • 500 $0.0046
  • 1,000 $0.0038
  • 5,000 $0.0026
  • 10,000 $0.0022
  • 20,000 $0.0020
  • 30,000 $0.0018
  • 50,000 $0.0017
  • 70,000 $0.0016
  • 100,000 $0.0015
  • 250,000 $0.0014
  • 500,000 $0.0013
  • 1,000,000 $0.0012
$0.0012 / $0.1000 Buy Now
DISTI # RMCF0402JT13K0
Avnet Americas - Tape and Reel (Alt: RMCF0402JT13K0) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 17 Weeks, 0 Days Container: Reel 40000 Factory Stock
  • 10,000 $0.0014
  • 20,000 $0.0014
  • 40,000 $0.0014
  • 60,000 $0.0014
  • 80,000 $0.0014
$0.0014 Buy Now
DISTI # 708-RMCF0402JT13K0
Mouser Electronics Thick Film Resistors - SMD RES, 0402, 13 Kohm, 5%, 0.0625W RoHS: Compliant 0
  • 10,000 $0.0010
$0.0010 Order Now
Onlinecomponents.com Thick Film Resistor - 13 kohm ±5% - 0.063W - SMD 0402 - Tape&Reel RoHS: Compliant 40000 Factory Stock
  • 10,000 $0.0014
  • 20,000 $0.0013
  • 40,000 $0.0012
  • 80,000 $0.0011
$0.0011 / $0.0014 Buy Now
DISTI # 27465791
Verical Res Thick Film 0402 13K Ohm 5% 0.063W(1/16W) ±100ppm/°C Pad SMD T/R Automotive AEC-Q200 Min Qty: 20000 Package Multiple: 10000 Americas - 40000
  • 20,000 $0.0051
  • 40,000 $0.0047
$0.0047 / $0.0051 Buy Now
NAC RESISTOR, 0402, 13 Kohm, 5%, 0.0625W - Thick film - General Purpose RoHS: Compliant Min Qty: 1 Package Multiple: 10000 40000
  • 10,000 $0.0030
  • 250,000 $0.0030
$0.0030 Buy Now
Master Electronics Thick Film Resistor - 13 kohm ±5% - 0.063W - SMD 0402 - Tape&Reel RoHS: Compliant 40000 Factory Stock
  • 10,000 $0.0014
  • 20,000 $0.0013
  • 40,000 $0.0012
  • 80,000 $0.0011
$0.0011 / $0.0014 Buy Now

Part Details for RMCF0402JT13K0

RMCF0402JT13K0 Part Data Attributes

Parametric Data
RMCF0402JT13K0 SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCF0402JT13K0 SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 0.063W, 13000ohm, 50V, 5% +/-Tol, 100ppm/Cel, Surface Mount, 0402, CHIP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STACKPOLE ELECTRONICS INC
Package Description CHIP
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 17 Weeks
Samacsys Manufacturer Stackpole Electronics, Inc.
Construction Rectangular
JESD-609 Code e3
Mounting Feature SURFACE MOUNT
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.3 mm
Package Length 1 mm
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Package Width 0.5 mm
Packing Method TR, Paper, 7 Inch
Rated Power Dissipation (P) 0.063 W
Rated Temperature 70 °C
Reference Standard AEC-Q200
Resistance 13000 Ω
Resistor Type FIXED RESISTOR
Size Code 0402
Surface Mount YES
Technology METAL GLAZE/THICK FILM
Temperature Coefficient 100 ppm/°C
Terminal Finish MATTE TIN OVER NICKEL
Terminal Shape WRAPAROUND
Tolerance 5%
Working Voltage 50 V

RMCF0402JT13K0 Related Parts

RMCF0402JT13K0 Frequently Asked Questions (FAQ)

  • The recommended land pattern for RMCF0402JT13K0 is a rectangular pad with a size of 0.5mm x 0.3mm, with a non-solder mask defined (NSMD) pad shape. The pad should be centered on the component and have a solder mask clearance of 0.1mm.

  • Yes, RMCF0402JT13K0 is rated for operation up to 150°C, making it suitable for high-temperature applications. However, the component's performance and reliability may degrade at temperatures above 125°C, so careful consideration should be given to the operating conditions.

  • To prevent damage, handle RMCF0402JT13K0 components by the edges or use a vacuum pickup tool. Avoid touching the component's terminals or body, as the oils from human skin can cause damage. Also, ensure that the component is not subjected to excessive mechanical stress, such as bending or flexing.

  • The recommended soldering profile for RMCF0402JT13K0 is a peak temperature of 260°C, with a dwell time of 10-30 seconds above 220°C. The soldering process should be done in a nitrogen atmosphere to prevent oxidation.

  • Yes, RMCF0402JT13K0 is rated for operation in humid environments, with a moisture sensitivity level (MSL) of 1. However, it's recommended to follow proper storage and handling procedures to prevent moisture absorption, and to ensure that the component is properly sealed or coated to prevent moisture ingress.
