RM48L940DZWTT by: Texas Instruments

16/32-Bit RISC Flash Microcontroller 337-NFBGA -40 to 105

Part Details for RM48L940DZWTT by Texas Instruments

Results Overview of RM48L940DZWTT by Texas Instruments

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Transportation and Logistics Automotive

RM48L940DZWTT Information

RM48L940DZWTT by Texas Instruments is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.

Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.

Price & Stock for RM48L940DZWTT

Part # Distributor Description Stock Price Buy
DISTI # RM48L940DZWTT-ND
DigiKey IC MCU 16/32B 3MB FLASH 337NFBGA Min Qty: 90 Lead time: 18 Weeks Container: Tray Temporarily Out of Stock
  • 90 $28.9274
$28.9274 Buy Now
DISTI # 595-RM48L940DZWTT
Mouser Electronics ARM Microcontrollers - MCU 16/32-Bit RISC Flash Microcontroller 337 RoHS: Compliant 0
  • 1 $39.6800
  • 10 $33.9300
  • 25 $32.5100
  • 50 $28.8500
  • 90 $28.8500
  • 100 $28.8300
  • 250 $28.6900
$28.6900 / $39.6800 Order Now

Part Details for RM48L940DZWTT

RM48L940DZWTT CAD Models

  • Part Symbol

    Part Symbol

  • Footprint
