3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for REM3.5E-0505S/R10/A/CTRL/X1 by RECOM Power GmbH
Results Overview of REM3.5E-0505S/R10/A/CTRL/X1 by RECOM Power GmbH
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
REM3.5E-0505S/R10/A/CTRL/X1 Information
REM3.5E-0505S/R10/A/CTRL/X1 by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for REM3.5E-0505S/R10/A/CTRL/X1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
71AC6833
|
Newark | Dc-Dc Converter, 5V, 0.7A, Power Supply Applications:Medical, Dc/Dc Converter Type:Dip, Input Ratio:2:1, Output Power Max:3.5W, No. Of Outputs:1 Output, Output Voltage - Output 1:5V, Output Current - Output 1:700Ma, Width:20.3Mm Rohs Compliant: Yes |Recom Power REM3.5E-0505S/R10/A/CTRL/X1 RoHS: Compliant Min Qty: 15 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$48.0400 / $64.6200 | Buy Now |
|
DISTI #
REM3.5E-0505S/R10/A/CTRL/X1-ND
|
DigiKey | DC DC CONVERTER 5V 3.5W Min Qty: 15 Lead time: 17 Weeks Container: Tube | Temporarily Out of Stock |
|
$53.4573 | Buy Now |
|
DISTI #
919-REM35E0505S10AC1
|
Mouser Electronics | Isolated DC/DC Converters - Through Hole 3.5W 4.5-9Vin 05Vout 700mA RoHS: Compliant | 0 |
|
$49.7800 / $50.9000 | Order Now |
|
DISTI #
51000500
|
RECOM Power | 3.5W DC/DC-Converter 'MEDLINE' DIP24 10kV reg 2:1 RoHS: Compliant | 0 |
|
RFQ | |
|
DISTI #
51000500
|
Richardson RFPD | DC TO DC CONVERTER MODULE RoHS: Compliant Min Qty: 15 | 0 |
|
$42.2900 | Buy Now |
|
DISTI #
000000000006060392
|
Sager | Isolated DC/DC Converters - Through Hole 3.5W 4.5-9Vin 05Vout 700mA Min Qty: 1 | 0 |
|
$48.3200 / $56.3800 | Buy Now |
Part Details for REM3.5E-0505S/R10/A/CTRL/X1
REM3.5E-0505S/R10/A/CTRL/X1 CAD Models
REM3.5E-0505S/R10/A/CTRL/X1 Part Data Attributes
|
|
REM3.5E-0505S/R10/A/CTRL/X1
RECOM Power GmbH
Buy Now
Datasheet
|
Compare Parts:
REM3.5E-0505S/R10/A/CTRL/X1
RECOM Power GmbH
DC-DC Regulated Power Supply Module
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | RECOM POWER GMBH | |
| Package Description | , | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | RECOM Power | |
| Analog IC - Other Type | DC-DC REGULATED POWER SUPPLY MODULE | |
| Approvals | IEC, EN, UL | |
| Efficiency (Main Output) | 76% | |
| Input Voltage-Max | 9 V | |
| Input Voltage-Min | 4.5 V | |
| Input Voltage-Nom | 5 V | |
| JESD-30 Code | R-PDMA-P7 | |
| JESD-609 Code | e3 | |
| Length | 31.8 mm | |
| Line Regulation-Max | 0.3% | |
| Load Regulation-Max | 0.5% | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 7 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.7 A | |
| Output Voltage-Max | 5.075 V | |
| Output Voltage-Min | 4.925 V | |
| Output Voltage-Nom | 5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | DMA | |
| Package Shape | RECTANGULAR | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | 255 | |
| Protections | SHORT CIRCUIT | |
| Ripple Voltage (Main Out) | 0.053025 Vrms | |
| Screening Level | IEC 60601-1 | |
| Seated Height-Max | 10.7 mm | |
| Surface Mount | NO | |
| Technology | HYBRID | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | PIN/PEG | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 5 | |
| Total Power Output-Max | 3.5 W | |
| Trim/Adjustable Output | NO | |
| Warm-up Time | 0.0006 s | |
| Width | 20.3 mm |
