REG102UA-A Information
REG102UA-A by Texas Instruments is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| REG102UA-5G4 | Texas Instruments | 250mA, Low-Noise, Low-Dropout Linear Voltage Regulator 8-SOIC -40 to 85 | |
| REG102UA-5/2K5 | Texas Instruments | 250mA, Low-Noise, Low-Dropout Linear Voltage Regulator 8-SOIC -40 to 85 | |
| REG102UA-3.3 | Texas Instruments | 250mA, Low-Noise, Low-Dropout Linear Voltage Regulator 8-SOIC -40 to 85 |
