3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for REC5-4809DRWZ/H4/A/SMD by RECOM Power GmbH
Results Overview of REC5-4809DRWZ/H4/A/SMD by RECOM Power GmbH
- Distributor Offerings: (5 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
REC5-4809DRWZ/H4/A/SMD Information
REC5-4809DRWZ/H4/A/SMD by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for REC5-4809DRWZ/H4/A/SMD
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
REC5-4809DRWZ/H4/A/SMD-ND
|
DigiKey | DC DC CONVERTER +/-9V 5W Min Qty: 15 Lead time: 17 Weeks Container: Tube | Temporarily Out of Stock |
|
$33.9393 | Buy Now |
|
DISTI #
919-5-4809DRWZH4AS
|
Mouser Electronics | Isolated DC/DC Converters - SMD 5W DC/DC 4kV REG 4:1 18-72Vin +/-9Vout RoHS: Compliant | 0 |
|
$31.1300 / $35.1700 | Order Now |
|
DISTI #
10010555
|
RECOM Power | 5W DC/DC-Converter 'ECONOLINE' SMD 4kV reg 4:1 RoHS: Compliant | 0 |
|
RFQ | |
|
|
Onlinecomponents.com | Dual Regulated DC-DC Converter - 5W - Input: 18 to 72VDC - Output: (+/-) 9VDC - 4kVDC Isolation - Metal Case - SMD RoHS: Compliant | 0 |
|
$27.2600 / $36.6600 | Buy Now |
|
DISTI #
000000000006058355
|
Sager | Isolated DC/DC Converters - SMD 5W DC/DC 4kV REG 4:1 18-72Vin +/-9Vout Min Qty: 1 | 0 |
|
$30.3700 / $35.4400 | Buy Now |
Part Details for REC5-4809DRWZ/H4/A/SMD
REC5-4809DRWZ/H4/A/SMD CAD Models
REC5-4809DRWZ/H4/A/SMD Part Data Attributes
|
|
REC5-4809DRWZ/H4/A/SMD
RECOM Power GmbH
Buy Now
Datasheet
|
Compare Parts:
REC5-4809DRWZ/H4/A/SMD
RECOM Power GmbH
Power Supply Module, 2 Output, 5W, Hybrid, SMD-24/18
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | RECOM POWER GMBH | |
| Package Description | SOP, GWDIP24,1.0 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | RECOM Power | |
| Additional Feature | OUTPUT -9 VOLT ALSO AVAILABLE | |
| Analog IC - Other Type | DC-DC REGULATED POWER SUPPLY MODULE | |
| Input Voltage-Max | 72 V | |
| Input Voltage-Min | 18 V | |
| Input Voltage-Nom | 48 V | |
| JESD-30 Code | R-PDMA-G18 | |
| JESD-609 Code | e1 | |
| Length | 32 mm | |
| Load Regulation-Max | 0.6% | |
| Number of Functions | 1 | |
| Number of Outputs | 2 | |
| Number of Terminals | 18 | |
| Operating Temperature-Max | 75 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.278 A | |
| Output Voltage-Max | 9.18 V | |
| Output Voltage-Min | 8.82 V | |
| Output Voltage-Nom | 9 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | GWDIP24,1.0 | |
| Package Shape | RECTANGULAR | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | 245 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 11.2 mm | |
| Surface Mount | YES | |
| Technology | HYBRID | |
| Temperature Grade | OTHER | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Total Power Output-Max | 5 W | |
| Trim/Adjustable Output | NO | |
| Width | 19.9 mm |
