REC5-0505SRW/H6/A/M/CTRL by: RECOM Power GmbH

Power Supply Module, 1 Output, 5W, Hybrid, DIP-24/9

Part Details for REC5-0505SRW/H6/A/M/CTRL by RECOM Power GmbH

Results Overview of REC5-0505SRW/H6/A/M/CTRL by RECOM Power GmbH

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation Renewable Energy Robotics and Drones

REC5-0505SRW/H6/A/M/CTRL Information

REC5-0505SRW/H6/A/M/CTRL by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Available Datasheets

Part # Manufacturer Description Datasheet
10123071-001C-TRLF Amphenol Communications Solutions SAS 3.0 Connectors, Storage & Server System, Receptacle, Vertical, Surface Mount, Wide Base, 29 Positions.
10031567-001C-TRLF Amphenol Communications Solutions SAS 3.0 Connectors, Storage & Server System, Receptacle, Vertical, Surface Mount, 29 Positions.
10120818-001C-TRLF Amphenol Communications Solutions SAS 3.0 Connectors, Storage and Server Connector, Receptacle, Vertical, Surface Mount, 29 Positions, 12Gb/s.

Price & Stock for REC5-0505SRW/H6/A/M/CTRL

Part # Distributor Description Stock Price Buy
DISTI # 63X4379
Newark 5W Dc/Dc-Converter Econoline Dip24 6Kv Reg 2:1 Rohs Compliant: Yes |Recom Power REC5-0505SRW/H6/A/M/CTRL RoHS: Compliant Min Qty: 15 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 1 $39.2600
  • 25 $35.9800
  • 50 $33.4200
  • 100 $32.3200
  • 250 $31.2300
$31.2300 / $39.2600 Buy Now
DISTI # REC5-0505SRW/H6/A/M/CTRL-ND
DigiKey DC DC CONVERTER 5V 5W Min Qty: 15 Lead time: 17 Weeks Container: Tube Temporarily Out of Stock
  • 15 $29.2480
$29.2480 Buy Now
DISTI # 919-5-0505SRWH6AMC
Mouser Electronics Isolated DC/DC Converters - Through Hole 5W DC/DC 6kV REG 2:1 4.5-9Vin 5Vout RoHS: Compliant 0
  • 1 $35.8200
  • 5 $35.5500
  • 10 $29.5100
  • 30 $29.5000
  • 105 $29.3800
  • 255 $29.0700
$29.0700 / $35.8200 Order Now
DISTI # 72130053
RS DC-DC Converter, DIP24, 6kV, Single, 5W, 05V, 1000mA, REC5-S_DRW(Z) Series Min Qty: 15 Package Multiple: 1 Lead time: 17 Weeks, 0 Days Container: Bulk 0
  • 15 $31.0100
  • 30 $29.4600
  • 60 $27.9100
$27.9100 / $31.0100 RFQ
Onlinecomponents.com Regulated DC-DC Converter - 5W - Input: 4.5 to 9VDC - Output: 5VDC - 6kVDC Isolation - CTRL Pin - Metal Case - DIP24 RoHS: Compliant 0
  • 1 $31.4800
  • 5 $29.4500
  • 15 $27.2500
  • 30 $26.4600
  • 60 $25.0100
  • 255 $24.3500
  • 510 $23.9800
$23.9800 / $31.4800 Buy Now
DISTI # 000000000006056192
Sager Isolated DC/DC Converters - Through Hole 5W DC/DC 6kV REG 2:1 4.5-9Vin 5Vout Min Qty: 1 0
  • 1 $30.4400
  • 5 $29.4500
  • 10 $28.0900
  • 25 $27.2600
  • 50 $26.8500
  • 100 $26.0800
$26.0800 / $30.4400 Buy Now

Part Details for REC5-0505SRW/H6/A/M/CTRL

REC5-0505SRW/H6/A/M/CTRL CAD Models

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

REC5-0505SRW/H6/A/M/CTRL Part Data Attributes

Parametric Data
REC5-0505SRW/H6/A/M/CTRL RECOM Power GmbH
Buy Now Datasheet
Compare Parts:
REC5-0505SRW/H6/A/M/CTRL RECOM Power GmbH Power Supply Module, 1 Output, 5W, Hybrid, DIP-24/9
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer RECOM POWER GMBH
Package Description DIP, DIP24,.6
Reach Compliance Code compliant
ECCN Code EAR99
Samacsys Manufacturer RECOM Power
Analog IC - Other Type DC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Max 9 V
Input Voltage-Min 4.5 V
Input Voltage-Nom 5 V
JESD-30 Code R-MDMA-P9
Length 32 mm
Load Regulation-Max 0.6%
Number of Functions 1
Number of Outputs 1
Number of Terminals 9
Operating Temperature-Max 75 °C
Operating Temperature-Min -40 °C
Output Current-Max 1 A
Output Voltage-Max 5.1 V
Output Voltage-Min 4.9 V
Output Voltage-Nom 5 V
Package Body Material METAL
Package Code DIP
Package Equivalence Code DIP24,.6
Package Shape RECTANGULAR
Package Style MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 10.45 mm
Surface Mount NO
Technology HYBRID
Temperature Grade OTHER
Terminal Form PIN/PEG
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 5
Total Power Output-Max 5 W
Trim/Adjustable Output NO
Width 20.3 mm

Alternate Parts for REC5-0505SRW/H6/A/M/CTRL

This table gives cross-reference parts and alternative options found for REC5-0505SRW/H6/A/M/CTRL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of REC5-0505SRW/H6/A/M/CTRL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
AM5T-0505SZ Aimtec $31.5525 DC/DC Converter; Product Weight (grams): 17; Input voltage min (V): 4.5; Input voltage max (V): 9; Output voltage min: 5; Output voltage max: 5; Output voltage dual assymetric (y/n): Single; Output Power (W): 5; Max Output current (A): 1; Efficiency (%): 77; Max Capacitive load (µF): 1000; Package type: DIP24; Mounting: PCB; W (in): 0.8; L (in): 1.25; H (in): 0.4; W (mm): 20.32; L (mm): 31.75; H (mm): 10.16; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 1500; EMC compliance 2: EN 55032 Class A; Case material: Copper; Application 4 (building automation/IoT): 1; MTBF (h): 1121000; Derating : 60; Voltage Accuracy (%): ±1; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 60; Switching Frequency typ (KHz): 266; Short circuit protection: Continuous REC5-0505SRW/H6/A/M/CTRL vs AM5T-0505SZ
REC5-0505SRW/H4/A/CTRL/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H4/A/CTRL/X2
REC5-0505SRW/H4/A/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H4/A/X2
JCD0505S05-H XP Power Check for Price DC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid, DIL-24/8 REC5-0505SRW/H6/A/M/CTRL vs JCD0505S05-H
REC5-0505SRW/H2/A/CTRL/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H2/A/CTRL/X2
REC5-0505SRW/H4/A/M/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H4/A/M/X2
REC5-0505SRW/H6/A/M/CTRL/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H6/A/M/CTRL/X2
REC5-0505SRW/H2/A/M/CTRL/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H2/A/M/CTRL/X2
REC5-0505SRW/H6/A/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module, REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H6/A/X2
REC5-0505SRW/H4/A/M/CTRL/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC5-0505SRW/H6/A/M/CTRL vs REC5-0505SRW/H4/A/M/CTRL/X2
