Power Circuits / Power Supply Modules / REC3-053.3SRW/H2/A/CTRL
Datasheets
REC3-053.3SRW/H2/A/CTRL by: RECOM Power GmbH

DC-DC Regulated Power Supply Module, 1 Output, 2.97W, Hybrid, DIP-24/9

Part Details for REC3-053.3SRW/H2/A/CTRL by RECOM Power GmbH

Results Overview of REC3-053.3SRW/H2/A/CTRL by RECOM Power GmbH

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Automotive

REC3-053.3SRW/H2/A/CTRL Information

REC3-053.3SRW/H2/A/CTRL by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Available Datasheets

Part # Manufacturer Description Datasheet
DRV8301DCA Texas Instruments 3-Phase Brushless Motor Pre-Driver with Dual Current Sense Amps and Buck Converter (PWM Ctrl w/ SPI) 56-HTSSOP -40 to 125
DRV8301DCAR Texas Instruments 3-Phase Brushless Motor Pre-Driver with Dual Current Sense Amps and Buck Converter (PWM Ctrl w/ SPI) 56-HTSSOP -40 to 125
74AC11000DR Texas Instruments Quadruple 2-Input Positive-NAND Gates 16-SOIC -40 to 85

Price & Stock for REC3-053.3SRW/H2/A/CTRL

Part # Distributor Description Stock Price Buy
DISTI # REC3-053.3SRW/H2/A/CTRL-ND
DigiKey DC DC CONVERTER 3.3V 3W Min Qty: 15 Lead time: 17 Weeks Container: Tube Temporarily Out of Stock
  • 15 $21.9253
$21.9253 Buy Now
DISTI # 10005890
RECOM Power 3W DC/DC-Converter 'ECONOLINE' DIP24 2kV reg 2:1 RoHS: Compliant 0
  • 1 $21.9300
$21.9300 RFQ
DISTI # 72101285
RS DC-DC Converter, DIP24, 2kV reg 2:1, 3W, 3.3V, 900mA, REC3-S_DRW(Z) Series Min Qty: 15 Package Multiple: 1 Lead time: 17 Weeks, 0 Days Container: Bulk 0
  • 15 $25.0900
  • 30 $23.5900
  • 60 $22.0800
$22.0800 / $25.0900 RFQ
Onlinecomponents.com Regulated DC-DC Converter - 3W - Input: 4.5 to 9VDC - Output: 3.3VDC - 2kV Isolation - CTRL Pin - DIP24 RoHS: Compliant 0
  • 1 $23.4500
  • 15 $20.9200
  • 30 $20.3000
  • 60 $19.4300
  • 105 $18.6300
  • 255 $18.1300
  • 510 $17.8600
$17.8600 / $23.4500 Buy Now
DISTI # 000000000006053046
Sager Isolated DC/DC Converters - Through Hole 3W DC/DC 2kV REG 2:1 4.5-9Vin 3.3Vout Min Qty: 1 0
  • 1 $22.6700
  • 5 $21.9300
  • 10 $20.9200
  • 25 $20.3100
  • 50 $20.0000
  • 100 $19.4400
$19.4400 / $22.6700 Buy Now

Part Details for REC3-053.3SRW/H2/A/CTRL

REC3-053.3SRW/H2/A/CTRL CAD Models

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

REC3-053.3SRW/H2/A/CTRL Part Data Attributes

Parametric Data
REC3-053.3SRW/H2/A/CTRL RECOM Power GmbH
Buy Now Datasheet
Compare Parts:
REC3-053.3SRW/H2/A/CTRL RECOM Power GmbH DC-DC Regulated Power Supply Module, 1 Output, 2.97W, Hybrid, DIP-24/9
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer RECOM POWER GMBH
Package Description DIP-24/9
Reach Compliance Code compliant
ECCN Code EAR99
kg CO2e/kg 12.04
Average Weight (mg) 5781.95
CO2e (mg) 69614.68
Samacsys Description 3W DC/DC-Converter 'ECONOLINE' DIP24 2kV reg 2:1
Samacsys Manufacturer RECOM Power
Samacsys Modified On 2024-07-24 15:52:31
Category CO2 Kg 504
Compliance Temperature Grade Commercial Extended: -40C to +80C
EU RoHS Version RoHS 2 (2015/863/EU)
Candidate List Date 2025-01-21
Conflict Mineral Status DRC Conflict Free
Conflict Mineral Status Source CMRT V6.31
Analog IC - Other Type DC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Max 9 V
Input Voltage-Min 4.5 V
Input Voltage-Nom 5 V
JESD-30 Code R-PDMA-P9
JESD-609 Code e3
Length 31.8 mm
Load Regulation-Max 0.6%
Number of Functions 1
Number of Outputs 1
Number of Terminals 9
Operating Temperature-Max 80 °C
Operating Temperature-Min -40 °C
Output Current-Max 0.9 A
Output Voltage-Max 3.366 V
Output Voltage-Min 3.234 V
Output Voltage-Nom 3.3 V
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP9/24,.6
Package Shape RECTANGULAR
Package Style MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 10.45 mm
Surface Mount NO
Technology HYBRID
Temperature Grade OTHER
Terminal Finish Tin (Sn)
Terminal Form PIN/PEG
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 5
Total Power Output-Max 2.97 W
Trim/Adjustable Output NO
Width 20.3 mm

Alternate Parts for REC3-053.3SRW/H2/A/CTRL

This table gives cross-reference parts and alternative options found for REC3-053.3SRW/H2/A/CTRL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of REC3-053.3SRW/H2/A/CTRL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
AM3G-0503SH30Z Aimtec $18.2554 DC/DC Converter; Product Weight (grams): 4.8; Input voltage min (V): 4.5; Input voltage max (V): 9; Output voltage min: 3.3; Output voltage max: 3.3; Output voltage dual assymetric (y/n): Single; Output Power (W): 2.31; Max Output current (A): 0.7; Efficiency (%): 74; Max Capacitive load (µF): 2200; Package type: SIP8; Mounting: PCB; W (in): 0.36; L (in): 0.86; H (in): 0.44; W (mm): 9.2; L (mm): 21.85; H (mm): 11.1; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 3000; EMC compliance 2: EN 55032 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 4 (building automation/IoT): 1; MTBF (h): 1340000; Derating : 71; Voltage Accuracy (%): ±1; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±1.0; Ripple & Noise (mV p-p): 75; Switching Frequency typ (KHz): 650; Short circuit protection: Continuous; On/Off Control: 1 REC3-053.3SRW/H2/A/CTRL vs AM3G-0503SH30Z
REC3-053.3SRW/H/B/SMD/CTRL RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H/B/SMD/CTRL
REC3-053.3SRW/H4/C/M/SMD RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module, 1 Output, 2.97W, Hybrid, SMD-24/18 REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H4/C/M/SMD
REC3-053.3SRW/H4/A/M/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H4/A/M/X2
REC3-053.3SRW/H6/C/M/CTRL/SMD-R RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H6/C/M/CTRL/SMD-R
REC3-053.3SRW/H2/A/M/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H2/A/M/X2
REC3-053.3SRW/H6/A/X2 RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module, 1 Output, 2.97W, Hybrid, DIP-24/8 REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H6/A/X2
REC3-053.3SRW/H6/A/M/SMD RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module, 1 Output, 2.97W, Hybrid, SMD-24/18 REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H6/A/M/SMD
REC3-053.3SRW/H4/C/SMD/CTRL-R RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H4/C/SMD/CTRL-R
REC3-053.3SRW/H/B/M/CTRL/SMD-R RECOM Power GmbH Check for Price DC-DC Regulated Power Supply Module REC3-053.3SRW/H2/A/CTRL vs REC3-053.3SRW/H/B/M/CTRL/SMD-R
