RCS12064R70JNEA Information
RCS12064R70JNEA by Vishay Intertechnologies is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for RCS12064R70JNEA
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
41AH5281
|
Newark | Res, 4R7, 5%, 0.5W, 1206, Thick Film, Resistance:4.7Ohm, Resistance Tolerance:± 5%, Power Rating:500Mw, Resistor Case/Package:1206 [3216 Metric], Resistor Technology:Thick Film, Resistor Type:Anti-Surge, Product Range:Rcs E3 Seriesrohs Compliant: Yes |Vishay RCS12064R70JNEA RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 4900 |
|
$0.0110 | Buy Now |
|
DISTI #
41AH5282
|
Newark | Res, 4R7, 5%, 0.5W, 1206, Thick Film, Resistance:4.7Ohm, Resistance Tolerance:± 5%, Power Rating:500Mw, Resistor Case/Package:1206 [3216 Metric], Resistor Technology:Thick Film, Resistor Type:Anti-Surge, Product Range:Rcs E3 Seriesrohs Compliant: Yes |Vishay RCS12064R70JNEA RoHS: Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
Buy Now | |
|
DISTI #
RCS12064R70JNEA
|
Avnet Americas | RCS1206 200 4R7 5% ET1 e3 - Tape and Reel (Alt: RCS12064R70JNEA) Min Qty: 5000 Package Multiple: 5000 Lead time: 12 Weeks, 0 Days Container: Reel | 0 |
|
$0.0249 / $0.0352 | Buy Now |
|
DISTI #
41AH5281
|
Avnet Americas | RCS1206 200 4R7 5% ET1 e3 - Product that comes on tape, but is not reeled (Alt: 41AH5281) RoHS: Not Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks, 3 Days Container: Ammo Pack | 0 |
|
$0.0530 / $0.2300 | Buy Now |
|
DISTI #
71-RCS12064R70JNEA
|
Mouser Electronics | Thick Film Resistors - SMD 0.5watt 4.7ohms 5% 200ppm RoHS: Compliant | 6573 |
|
$0.0270 / $0.2500 | Buy Now |
|
DISTI #
V72:2272_24012575
|
Arrow Electronics | Res Thick Film 1206 4.7 Ohm 5% 0.5W(1/2W) ±200ppm/°C Pad SMD T/R Automotive AEC-Q200 Medical Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 1949 Container: Cut Strips | Americas - 2200 |
|
$0.0043 / $0.0384 | Buy Now |
|
DISTI #
60334844
|
Verical | Res Thick Film 1206 4.7 Ohm 5% 0.5W(1/2W) ±200ppm/°C Pad SMD T/R Automotive AEC-Q200 Medical Min Qty: 4546 Package Multiple: 1 | Americas - 4900 |
|
$0.0156 | Buy Now |
|
|
Quest Components | FIXED RESISTOR, METAL GLAZE/THICK FILM, 0.5W, 4.7OHM, 200V, 5% +/-TOL, 200PPM/CEL, SURFACE MOUNT, 1206 | 1640 |
|
$0.0405 / $0.0900 | Buy Now |
|
DISTI #
RCS12064R70JNEA
|
Avnet Abacus | RCS1206 200 4R7 5 ET1 e3 - Tape and Reel (Alt: RCS12064R70JNEA) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 15 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now |
Part Details for RCS12064R70JNEA
RCS12064R70JNEA CAD Models
RCS12064R70JNEA Part Data Attributes
|
|
RCS12064R70JNEA
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
RCS12064R70JNEA
Vishay Intertechnologies
Fixed Resistor, Metal Glaze/thick Film, 0.5W, 4.7ohm, 200V, 5% +/-Tol, 200ppm/Cel, Surface Mount, 1206, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.30 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | LASER TRIMMABLE, RATED AC VOLTAGE (V): 200 | |
| Construction | Rectangular | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 155 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Height | 0.55 mm | |
| Package Length | 3.2 mm | |
| Package Style | SMT | |
| Package Width | 1.6 mm | |
| Packing Method | TR, PAPER, 7 INCH | |
| Rated Power Dissipation (P) | 0.5 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 4.7 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 1206 | |
| Surface Mount | YES | |
| Technology | METAL GLAZE/THICK FILM | |
| Temperature Coefficient | 200 ppm/°C | |
| Terminal Finish | Tin (Sn) - with Nickel (Ni) barrier | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 5% | |
| Working Voltage | 200 V |
RCS12064R70JNEA Frequently Asked Questions (FAQ)
-
The recommended soldering temperature is 260°C (500°F) for 10 seconds, with a peak temperature of 280°C (536°F) for 5 seconds.
-
Yes, the RCS12064R70JNEA is designed for high-frequency applications up to 1 GHz, with a low inductance of 0.5 nH and a high self-resonant frequency.
-
The power rating of the RCS12064R70JNEA decreases with temperature. At 70°C, the power rating is 120 mW, and at 125°C, it is 60 mW.
-
Yes, the RCS12064R70JNEA is AEC-Q200 qualified, which means it meets the stringent requirements for automotive applications.
-
The MSL of the RCS12064R70JNEA is 1, which means it can withstand exposure to moisture without damage during the soldering process.
