Power Circuits / Power Supply Modules / R2D-1209
Datasheets
R2D-1209 by: RECOM Power GmbH

DC-DC Unregulated Power Supply Module, 2 Output, 2W, Hybrid, SMD-10/6

Part Details for R2D-1209 by RECOM Power GmbH

Results Overview of R2D-1209 by RECOM Power GmbH

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

R2D-1209 Information

R2D-1209 by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Available Datasheets

Part # Manufacturer Description Datasheet
91911-21209LF Amphenol Communications Solutions Conan® 1.00mm Pitch, Board To Board Connector, I - Industrial Series, Vertical Header, Surface Mount, 9 Positions, 1.00mm ( 0.039in) Pitch.
91901-31209LF Amphenol Communications Solutions Conan® 1.00mm Pitch, Board To Board Connector, I - Industrial Series, Vertical Header, Surface Mount, 9 Positions.
91911-31209LF Amphenol Communications Solutions Conan® 1.00mm Pitch, Board To Board Connector, I - Industrial Series, Vertical Header, Surface Mount, 9 Positions, 1.00mm ( 0.039in) Pitch.

Price & Stock for R2D-1209

Part # Distributor Description Stock Price Buy
DISTI # 64X5265
Newark 2W Dc/Dc-Converter Econoline Smd 1Kv Unreg Rohs Compliant: Yes |Recom Power R2D-1209 RoHS: Compliant Min Qty: 33 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 1 $17.0700
  • 50 $15.4800
  • 100 $14.1900
  • 250 $13.1800
  • 500 $12.3200
$12.3200 / $17.0700 Buy Now
DISTI # 2266-R2D-1209-ND
DigiKey DC DC CONVERTER +/-9V 2W Min Qty: 1 Lead time: 16 Weeks Container: Retail Package MARKETPLACE PRODUCT 33
In Stock
  • 10 $10.1700
$10.1700 Buy Now
DISTI # 945-2816-ND
DigiKey DC DC CONVERTER +/-9V 2W Min Qty: 1 Lead time: 16 Weeks Container: Tube 4
In Stock
  • 1 $12.5500
  • 5 $12.0800
  • 10 $11.8840
  • 25 $11.6296
  • 50 $11.4408
  • 100 $11.2548
  • 250 $11.0132
  • 500 $10.8336
$10.8336 / $12.5500 Buy Now
DISTI # 919-R2D-1209
Mouser Electronics Isolated DC/DC Converters - SMD 2W DC/DC 1kV UNREG 12Vin +/-9Vout RoHS: Compliant 3
  • 1 $12.7000
  • 10 $12.5600
  • 25 $12.1200
  • 50 $12.1100
  • 99 $11.1200
  • 264 $10.7300
  • 528 $10.6700
$10.6700 / $12.7000 Buy Now
Onlinecomponents.com Unregulated DC-DC Converter - Dual Output - 2 W - Input: 12VDC (+/-) 10% - Output: (+/-) 9VDC - 10 lead SMD RoHS: Compliant 33 Partner Stock
  • 5 $12.6600
  • 33 $11.4800
  • 66 $10.9700
  • 132 $10.5000
  • 264 $10.0600
  • 528 $9.7900
  • 1,023 $9.6500
$9.6500 / $12.6600 Buy Now
DISTI # R2D-1209
IBS Electronics 2W DC/DC-CONVERTER ECONOLINE SMD 1KV UNREG V. IN: 12 V. OUT: &#x2B, /-09 MA. OUT: &#x2B, /-111 Min Qty: 15 Package Multiple: 1 33
  • 15 $15.0250
$15.0250 Buy Now
DISTI # R2D-1209
Richardson RFPD DC TO DC CONVERTER MODULE RoHS: Compliant Min Qty: 1 113
  • 1 $6.0200
$6.0200 Buy Now
DISTI # 000000000006050140
Sager Isolated DC/DC Converters - SMD 2W DC/DC 1kV UNREG 12Vin +/-9Vout Min Qty: 1 0
  • 1 $12.0100
  • 5 $11.6200
  • 10 $11.0900
  • 25 $10.7400
  • 50 $10.5800
  • 100 $10.2800
$10.2800 / $12.0100 Buy Now
Master Electronics Unregulated DC-DC Converter - Dual Output - 2 W - Input: 12VDC (+/-) 10% - Output: (+/-) 9VDC - 10 lead SMD RoHS: Compliant 33 Partner Stock
  • 5 $12.6600
  • 33 $11.4800
  • 66 $10.9700
  • 132 $10.5000
  • 264 $10.0600
  • 528 $9.7900
  • 1,023 $9.6500
$9.6500 / $12.6600 Buy Now

Part Details for R2D-1209

R2D-1209 Part Data Attributes

Parametric Data
R2D-1209 RECOM Power GmbH
Buy Now Datasheet
Compare Parts:
R2D-1209 RECOM Power GmbH DC-DC Unregulated Power Supply Module, 2 Output, 2W, Hybrid, SMD-10/6
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer RECOM POWER GMBH
Package Description SMD-10/6
Reach Compliance Code compliant
ECCN Code EAR99
Samacsys Manufacturer RECOM Power
Additional Feature SEATED HGT CALCULATED
Analog IC - Other Type DC-DC UNREGULATED POWER SUPPLY MODULE
Input Voltage-Max 13.2 V
Input Voltage-Min 10.8 V
Input Voltage-Nom 12 V
JESD-30 Code R-XDMA-F6
Length 15.24 mm
Load Regulation-Max 10%
Number of Functions 1
Number of Outputs 2
Number of Terminals 6
Operating Temperature-Max 100 °C
Operating Temperature-Min -40 °C
Output Current-Max 0.111 A
Output Voltage-Max 9.45 V
Output Voltage-Min 8.55 V
Output Voltage-Nom 9 V
Package Body Material UNSPECIFIED
Package Code SOP
Package Equivalence Code GWDIP6/10,.48
Package Shape RECTANGULAR
Package Style MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Cel) 255
Qualification Status Not Qualified
Seated Height-Max 9.5 mm
Surface Mount YES
Technology HYBRID
Temperature Grade INDUSTRIAL
Terminal Form FLAT
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 5
Total Power Output-Max 2 W
Trim/Adjustable Output NO
Width 10.7 mm
