R12P12S/P/X2 by: RECOM Power GmbH

DC-DC Unregulated Power Supply Module, 1 Output, 1W, Hybrid, SIP-7/4

Part Details for R12P12S/P/X2 by RECOM Power GmbH

Results Overview of R12P12S/P/X2 by RECOM Power GmbH

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

R12P12S/P/X2 Information

R12P12S/P/X2 by RECOM Power GmbH is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Price & Stock for R12P12S/P/X2

Part # Distributor Description Stock Price Buy
DISTI # 64X4897
Newark 1W Dc/Dc-Converter Econoline Sip7 6.4Kv Unreg |Recom Power R12P12S/P/X2 RoHS: Not Compliant Min Qty: 25 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 1 $21.3100
  • 50 $19.3300
  • 100 $17.7100
  • 250 $16.4600
  • 500 $15.3800
$15.3800 / $21.3100 Buy Now
DISTI # R12P12S/P/X2-ND
DigiKey DC DC CONVERTER 12V 1W Min Qty: 25 Lead time: 16 Weeks Container: Tube Temporarily Out of Stock
  • 25 $14.4504
$14.4504 Buy Now
DISTI # 10016411
RECOM Power 1W DC/DC-Converter 'ECONOLINE' SIP7 6.4kV unreg RoHS: Compliant 0
  • 1 $14.4500
$14.4500 RFQ
Onlinecomponents.com DC-DC Converter - 1 Watt - SIP - Input: 12VDC (+/-) 10% - Output: 12VDC - Short Circuit Protection - -40°C to +85°C RoHS: Compliant 2 Factory Stock
  • 1 $17.0500
  • 5 $15.5000
  • 25 $14.0500
  • 50 $13.4200
  • 100 $12.8400
  • 250 $12.3200
  • 500 $11.9900
  • 1,000 $11.8100
$11.8100 / $17.0500 Buy Now
DISTI # R12P12S/P/X2
Richardson RFPD DC TO DC CONVERTER MODULE RoHS: Compliant Min Qty: 25 0
  • 25 $11.2400
$11.2400 Buy Now
DISTI # 000000000006047971
Sager Isolated DC/DC Converters - Through Hole 1W 12VIN 12VOUT CONT SHORT CIR PRTCT Min Qty: 1 0
  • 1 $14.9700
  • 5 $14.5000
  • 10 $13.8300
  • 25 $13.4100
  • 50 $13.2100
  • 100 $12.8600
$12.8600 / $14.9700 Buy Now
Master Electronics DC-DC Converter - 1 Watt - SIP - Input: 12VDC (+/-) 10% - Output: 12VDC - Short Circuit Protection - -40°C to +85°C RoHS: Compliant 2 Factory Stock
  • 1 $17.0500
  • 5 $15.5000
  • 25 $14.0500
  • 50 $13.4200
  • 100 $12.8400
  • 250 $12.3200
  • 500 $11.9900
  • 1,000 $11.8100
$11.8100 / $17.0500 Buy Now

Part Details for R12P12S/P/X2

R12P12S/P/X2 Part Data Attributes

Parametric Data
R12P12S/P/X2 RECOM Power GmbH
Buy Now Datasheet
Compare Parts:
R12P12S/P/X2 RECOM Power GmbH DC-DC Unregulated Power Supply Module, 1 Output, 1W, Hybrid, SIP-7/4
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer RECOM POWER GMBH
Part Package Code MODULE
Package Description SIP-7/4
Pin Count 7/4
Reach Compliance Code compliant
ECCN Code EAR99
Samacsys Manufacturer RECOM Power
Analog IC - Other Type DC-DC UNREGULATED POWER SUPPLY MODULE
Approvals CB, CSA, EN, IEC, UL
Control Mode VOLTAGE-MODE
Efficiency (Main Output) 82%
Input Voltage-Max 13.2 V
Input Voltage-Min 10.8 V
Input Voltage-Nom 12 V
JESD-30 Code R-XSMA-P4
JESD-609 Code e3
Length 19.5 mm
Load Regulation-Max 10%
Number of Functions 1
Number of Outputs 1
Number of Terminals 4
Operating Temperature-Max 90 °C
Operating Temperature-Min -40 °C
Output Current-Max 0.084 A
Output Voltage-Max 12.6 V
Output Voltage-Min 11.4 V
Output Voltage-Nom 12 V
Package Body Material UNSPECIFIED
Package Code SMA
Package Shape RECTANGULAR
Package Style MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Cel) 255
Protections OUTPUT OVER CURRENT
Ripple Voltage (Main Out) 0.0707 Vrms
Seated Height-Max 13 mm
Surface Mount NO
Technology HYBRID
Temperature Grade INDUSTRIAL
Terminal Finish Tin (Sn)
Terminal Form PIN/PEG
Terminal Pitch 2.54 mm
Terminal Position SINGLE
Time@Peak Reflow Temperature-Max (s) 5
Total Power Output-Max 1 W
Trim/Adjustable Output NO
Width 9.8 mm

Alternate Parts for R12P12S/P/X2

This table gives cross-reference parts and alternative options found for R12P12S/P/X2. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of R12P12S/P/X2, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
MAPU01-12S12HA Minmax Technology Co Ltd Check for Price DC-DC Regulated Power Supply Module, 1 Output, 1W, Hybrid, SIP-6/5 R12P12S/P/X2 vs MAPU01-12S12HA
MAPU01-12S12H Minmax Technology Co Ltd Check for Price DC-DC Regulated Power Supply Module, 1 Output, 1W, Hybrid, SIP-7/5 R12P12S/P/X2 vs MAPU01-12S12H
R12P12S/R8/X2 RECOM Power GmbH Check for Price DC-DC Unregulated Power Supply Module, R12P12S/P/X2 vs R12P12S/R8/X2
