QMS-026-06.75-L-D-PC4 by: Samtec Inc

Board Stacking Connector, 60 Contact(s), 2 Row(s), Male, Straight, 0.025 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle, ROHS COMPLIANT

Part Details for QMS-026-06.75-L-D-PC4 by Samtec Inc

Results Overview of QMS-026-06.75-L-D-PC4 by Samtec Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Internet of Things (IoT) Computing and Data Storage Aerospace and Defense Healthcare Telecommunications Automotive

QMS-026-06.75-L-D-PC4 Information

QMS-026-06.75-L-D-PC4 by Samtec Inc is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Price & Stock for QMS-026-06.75-L-D-PC4

Part # Distributor Description Stock Price Buy
DISTI # 96P2453
Newark Header, 0.635Mm, High Speed, 2X26 Position, Mezzanine Connector Type:Header, Pitch Spacing:0.635Mm, No. Of Rows:2Rows, No. Of Contacts:52Contacts, Connector Mounting:Surface Mount, Contact Material:Phosphor Bronze, Gender:Header Rohs Compliant: Yes |Samtec QMS-026-06.75-L-D-PC4 RoHS: Compliant Min Qty: 56 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 50 $7.8200
  • 100 $6.8700
  • 250 $6.4200
  • 500 $6.2900
$6.2900 / $7.8200 Buy Now
DISTI # SAM9764-ND
DigiKey CONN HDR 52POS SMD GOLD Min Qty: 1 Lead time: 6 Weeks Container: Tray 80
In Stock
  • 1 $12.1900
  • 112 $9.7001
  • 224 $8.8700
  • 448 $8.7240
$8.7240 / $12.1900 Buy Now
DISTI # QMS-026-06.75-L-D-PC4
Avnet Americas Mezzanine Connector, Ground Plane, Header, 0.635 mm, 2 Rows, 52 Contacts, Surface Mount - Trays (Alt: QMS-026-06.75-L-D-PC4) RoHS: Compliant Min Qty: 56 Package Multiple: 56 Lead time: 2 Weeks, 4 Days Container: Tray 0
  • 56 $11.6923
  • 112 $9.1240
  • 224 $8.4010
  • 336 $8.2648
  • 448 $6.7601
$6.7601 / $11.6923 Buy Now
DISTI # 200-QMS02606.75LDPC4
Mouser Electronics Headers & Wire Housings 0.635 mm Q2(TM) High-Speed Rugged Ground Plane Terminal Strip RoHS: Compliant 738
  • 1 $12.1900
  • 112 $9.7000
  • 280 $8.8700
  • 504 $7.3900
$7.3900 / $12.1900 Buy Now
Onlinecomponents.com 0.635 mm Q2™ High-Speed Rugged Ground Plane Combo Power Terminal Strip RoHS: Compliant 0
  • 5 $15.7200
  • 25 $14.2500
  • 56 $13.2200
  • 112 $10.3900
  • 280 $9.3600
  • 504 $7.5900
  • 1,008 $7.4700
$7.4700 / $15.7200 Buy Now
DISTI # 000000000002649135
Sager Headers & Wire Housings 0.635 mm Q2 High-Speed Rugged Ground Plane Terminal Strip Min Qty: 56 0
  • 56 $12.1900
  • 112 $9.7000
  • 224 $8.8700
  • 448 $7.2100
  • 1,792 $5.5400
  • 4,872 $5.1300
$5.1300 / $12.1900 Buy Now
DISTI # QMS-026-06.75-L-D-PC4
Avnet Abacus Mezzanine Connector Ground Plane Header 0635 mm 2 Rows 52 Contacts Surface Mount (Alt: QMS-026-06.75-L-D-PC4) RoHS: Compliant Min Qty: 56 Package Multiple: 56 Lead time: 4 Weeks, 0 Days Abacus - 0
Buy Now
DISTI # QMS-026-06.75-L-D-PC4
Avnet Abacus Mezzanine Connector Ground Plane Header 0635 mm 2 Rows 52 Contacts Surface Mount (Alt: QMS-026-06.75-L-D-PC4) RoHS: Compliant Min Qty: 56 Package Multiple: 56 Lead time: 9 Weeks, 0 Days Abacus - 0
Buy Now
Master Electronics 0.635 mm Q2™ High-Speed Rugged Ground Plane Combo Power Terminal Strip RoHS: Compliant 0
  • 5 $15.7200
  • 25 $14.2500
  • 56 $13.2200
  • 112 $10.3900
  • 280 $9.3600
  • 504 $7.5900
  • 1,008 $7.4700
$7.4700 / $15.7200 Buy Now

Part Details for QMS-026-06.75-L-D-PC4

QMS-026-06.75-L-D-PC4 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

QMS-026-06.75-L-D-PC4 Part Data Attributes

Parametric Data
QMS-026-06.75-L-D-PC4 Samtec Inc
Buy Now Datasheet
Compare Parts:
QMS-026-06.75-L-D-PC4 Samtec Inc Board Stacking Connector, 60 Contact(s), 2 Row(s), Male, Straight, 0.025 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle, ROHS COMPLIANT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer SAMTEC INC
Reach Compliance Code compliant
Factory Lead Time 2 Weeks, 4 Days
Samacsys Manufacturer SAMTEC
Additional Feature TERMINAL PITCH FOR POWER CONTACTS IS 2 MM, Q2
Board Mounting Option PEG
Body Breadth 0.296 inch
Body Depth 0.25 inch
Body Length 1.36 inch
Body/Shell Style PLUG
Connector Type BOARD STACKING CONNECTOR
Contact Arrangement S52P8
Contact Finish Mating GOLD (10) OVER NICKEL (50)
Contact Finish Termination Tin (Sn) - with Nickel (Ni) barrier
Contact Gender MALE
Contact Material PHOSPHOR BRONZE
Contact Pattern RECTANGULAR
Contact Style HYBRID
DIN Conformance NO
Filter Feature NO
IEC Conformance NO
Insulator Color BLACK
Insulator Material LIQUID CRYSTAL POLYMER
JESD-609 Code e3
MIL Conformance NO
Mating Contact Pitch 0.025 inch
Mating Contact Row Spacing 0.116 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts YES
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Mounting Type BOARD
Number Of Connectors ONE
Number Of PCB Rows 2
Number of Rows Loaded 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Option GENERAL PURPOSE
PCB Contact Pattern RECTANGULAR
PCB Contact Row Spacing 6.73 mm
Plating Thickness 10u inch
Polarization Key POLARIZED HOUSING
Rated Current (Power) 4 A
Rated Current (Signal) 2.6 A
Reference Standard UL
Terminal Pitch 0.635 mm
Termination Type SOLDER/SURFACE MOUNT
Total Number of Contacts 60
UL Flammability Code 94V-0
