Switches / Pushbutton Switches / PV7F2T0SS-324
Datasheets
PV7F2T0SS-324 by:

Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount

Part Details for PV7F2T0SS-324 by E-Switch Inc

Results Overview of PV7F2T0SS-324 by E-Switch Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Space Technology Environmental Monitoring Internet of Things (IoT) Smart Cities Agriculture Technology Virtual Reality (VR), Augmented Reality (AR), and Vision Systems Medical Imaging Consumer Electronics Education and Research Security and Surveillance Aerospace and Defense Healthcare Robotics and Drones

PV7F2T0SS-324 Information

PV7F2T0SS-324 by E-Switch Inc is a Pushbutton Switch.
Pushbutton Switches are under the broader part category of Switches.

Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.

Price & Stock for PV7F2T0SS-324

Part # Distributor Description Stock Price Buy
DISTI # 76T6924
Newark Ea Rohs Compliant: Yes |E-Switch PV7F2T0SS-324 RoHS: Compliant Min Qty: 20 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 1 $32.2500
  • 5,000 $31.1500
  • 10,000 $30.1100
$30.1100 / $32.2500 Buy Now
DISTI # EG5257-ND
DigiKey SWITCH PUSHBUTTON SPDT 2A 48V Min Qty: 1 Lead time: 14 Weeks Container: Bulk 9
In Stock
  • 1 $28.8400
  • 20 $23.7990
  • 40 $22.7600
  • 60 $22.1725
  • 100 $21.4531
  • 260 $20.1667
  • 500 $19.3290
$19.3290 / $28.8400 Buy Now
DISTI # 612-PV7F2T0SS-324
Mouser Electronics Pushbutton Switches Illuminated, Sealed Anti-vandal switch 0
  • 1 $28.5200
  • 10 $28.0000
  • 20 $22.7600
  • 60 $22.1700
  • 100 $21.4500
  • 260 $20.1600
$20.1600 / $28.5200 Order Now
DISTI # 74830173
RS Anti-Vandal Switch, DPST-NO/NC, OFF-ON, ON-OFF, 2A, 48V DC, Solder, IP65 Min Qty: 20 Package Multiple: 1 Lead time: 14 Weeks, 0 Days Container: Bulk 0
  • 20 $42.3600
$42.3600 RFQ

Part Details for PV7F2T0SS-324

PV7F2T0SS-324 Part Data Attributes

Parametric Data
PV7F2T0SS-324 E-Switch Inc
Buy Now Datasheet
Compare Parts:
PV7F2T0SS-324 E-Switch Inc Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer E-SWITCH INC
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8536.50.90.33
Samacsys Manufacturer E-Switch
Actuator Length 0.079 inch
Actuator Material STAINLESS STEEL
Actuator Type PUSHBUTTON
Additional Feature ROHS COMPLIANT
Body Length or Diameter 24.7904 mm
Center Contact Plating SILVER
Contact Current(DC)-Max 2 A
Contact (DC) Max Rating R Load 2A@48VDC
Contact Function OFF-ON-OFF
Contact Resistance 0.05 mΩ
Contact Voltage(DC)-Max 48 V
Dielectric Withstand Volts 2000VAC V
Electrical Life 50000 Cycle(s)
End Contact Plating SILVER
Housing Material STAINLESS STEEL
Illumination NON-ILLUMINATED
Insulation Resistance 1000000000 Ω
Insulator Material POLYBUTYLENE TEREPHTHALATE
Mounting Feature PANEL MOUNT
Operating Temperature-Max 70 °C
Operating Temperature-Min -20 °C
Surface Mount NO
Switch Action LATCHED
Switch Function DPST
Switch Type VANDAL-RESISTANT SWITCH
Termination Type SOLDER

Alternate Parts for PV7F2T0SS-324

This table gives cross-reference parts and alternative options found for PV7F2T0SS-324. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of PV7F2T0SS-324, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
PV7F2T0SS-254 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0SS-254
PV7F2T0SN-341 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0SN-341
PV7F2T0NS-335 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NS-335
PV7F2T0SN-305 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0SN-305
PV7F2T0NNG-336 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NNG-336
PV7F2T0NS-337 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NS-337
PV7F2T0NSG-234 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NSG-234
PV7F2T0NNG-347 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NNG-347
PV7F2T0NNG-225 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NNG-225
PV7F2T0NSG-213 E-Switch Inc Check for Price Pushbutton Switch, DPST, Off-on-off, Maintained, 2A, 48VDC, Solder Lug Terminal, Panel Mount PV7F2T0SS-324 vs PV7F2T0NSG-213
