PMEG4010ESB - 40 V, 1 A low VF MEGA Schottky barrier rectifier@en-us

Part Details for PMEG4010ESBYL by Nexperia

Results Overview of PMEG4010ESBYL by Nexperia

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Energy and Power Systems Transportation and Logistics Renewable Energy Automotive

PMEG4010ESBYL Information

PMEG4010ESBYL by Nexperia is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.

Price & Stock for PMEG4010ESBYL

Part # Distributor Description Stock Price Buy
DISTI # 68Y7836
Newark Schottky Rectifier, Single, 40 V, 1 A, Sod-993, 2, 610 Mv Rohs Compliant: Yes |Nexperia PMEG4010ESBYL RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape 2932
  • 1 $0.1930
  • 10 $0.1310
  • 25 $0.1180
  • 50 $0.1050
  • 100 $0.0920
  • 250 $0.0870
  • 500 $0.0820
  • 1,000 $0.0770
$0.0770 / $0.1930 Buy Now
DISTI # 1727-8542-1-ND
DigiKey DIODE SCHOTTKY 40V 1A DSN1006-2 Min Qty: 1 Lead time: 8 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) 9754
In Stock
  • 1 $0.1900
  • 10 $0.1280
  • 100 $0.1182
  • 500 $0.0873
  • 1,000 $0.0727
  • 2,000 $0.0688
  • 5,000 $0.0595
  • 10,000 $0.0424
  • 20,000 $0.0420
  • 30,000 $0.0409
  • 50,000 $0.0386
$0.0386 / $0.1900 Buy Now
DISTI # PMEG4010ESBYL
Avnet Americas Diode Schottky 40V 1A 2-Pin SOD-993 T/R - Tape and Reel (Alt: PMEG4010ESBYL) RoHS: Compliant Min Qty: 20000 Package Multiple: 10000 Lead time: 8 Weeks, 0 Days Container: Reel 0
  • 20,000 $0.0414
  • 40,000 $0.0399
  • 60,000 $0.0383
  • 100,000 $0.0368
  • 200,000 $0.0352
$0.0352 / $0.0414 Buy Now
DISTI # 771-PMEG4010ESBYL
Mouser Electronics Schottky Diodes & Rectifiers 40 V, 1 A very low VF Schottky barrier rectifier RoHS: Compliant 66995
  • 1 $0.1900
  • 10 $0.1280
  • 100 $0.1050
  • 500 $0.0880
  • 1,000 $0.0670
  • 2,500 $0.0630
  • 5,000 $0.0560
  • 10,000 $0.0420
$0.0420 / $0.1900 Buy Now
DISTI # V72:2272_09156741
Arrow Electronics Diode Schottky 1.4A 2-Pin DSN T/R RoHS: Compliant Min Qty: 2513 Package Multiple: 1 Lead time: 8 Weeks Date Code: 2124 Container: Cut Strips Americas - 4266
  • 2,513 $0.0398
  • 3,000 $0.0396
$0.0396 / $0.0398 Buy Now
DISTI # PMEG4010ESBYL
TTI Schottky Diodes & Rectifiers 40 V, 1 A very low VF Schottky barrier rectifier RoHS: Compliant pbFree: Pb-Free Min Qty: 20000 Package Multiple: 10000 Container: Reel Americas - 0
  • 20,000 $0.0410
  • 30,000 $0.0400
  • 50,000 $0.0390
  • 100,000 $0.0380
  • 200,000 $0.0380
$0.0380 / $0.0410 Buy Now
DISTI # PMEG4010ESBYL
IBS Electronics IN A PACK OF 50 NEXPERIA 40V 1.4A SCHOTTKY DIODE 2-PIN DSN-1006-2 PMEG4010ESBYL Min Qty: 30000 Package Multiple: 1 0
  • 20,000 $0.0449
  • 30,000 $0.0455
  • 30,000 $0.0443
  • 40,000 $0.0441
  • 50,000 $0.0432
$0.0432 / $0.0455 Buy Now
DISTI # PMEG4010ESBYL
Avnet Asia Diode Schottky 40V 1A 2-Pin SOD-993 T/R (Alt: PMEG4010ESBYL) RoHS: Compliant Min Qty: 20000 Package Multiple: 10000 Lead time: 8 Weeks, 0 Days 0
  • 20,000 $0.0358
  • 40,000 $0.0353
  • 60,000 $0.0349
  • 100,000 $0.0344
  • 200,000 $0.0336
  • 500,000 $0.0328
  • 1,000,000 $0.0320
$0.0320 / $0.0358 Buy Now
DISTI # PMEG4010ESBYL
Avnet Silica Diode Schottky 40V 1A 2Pin SOD993 TR (Alt: PMEG4010ESBYL) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 10 Weeks, 0 Days Silica - 20000
Buy Now
DISTI # PMEG4010ESBYL
EBV Elektronik Diode Schottky 40V 1A 2Pin SOD993 TR (Alt: PMEG4010ESBYL) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 10 Weeks, 0 Days EBV - 80000
Buy Now
LCSC 40V 610mV1A 1A DSN1006-2 Schottky Diodes ROHS 305
  • 5 $0.0958
  • 50 $0.0937
  • 150 $0.0923
  • 500 $0.0909
$0.0909 / $0.0958 Buy Now

Part Details for PMEG4010ESBYL

PMEG4010ESBYL Part Data Attributes

Parametric Data
PMEG4010ESBYL Nexperia
Buy Now Datasheet
Compare Parts:
PMEG4010ESBYL Nexperia PMEG4010ESB - 40 V, 1 A low VF MEGA Schottky barrier rectifier@en-us
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer NEXPERIA
Package Description DSN1006-2, 2 PIN
Manufacturer Package Code SOD993
Reach Compliance Code compliant
Factory Lead Time 8 Weeks
Samacsys Manufacturer Nexperia
Application GENERAL PURPOSE
Configuration SINGLE
Diode Element Material SILICON
Diode Type RECTIFIER DIODE
Forward Voltage-Max (VF) 0.61 V
JESD-30 Code R-PBCC-N2
Moisture Sensitivity Level 1
Non-rep Pk Forward Current-Max 10 A
Number of Elements 1
Number of Phases 1
Number of Terminals 2
Operating Temperature-Max 150 °C
Operating Temperature-Min -55 °C
Output Current-Max 1 A
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style CHIP CARRIER
Peak Reflow Temperature (Cel) 260
Power Dissipation-Max 0.28 W
Reference Standard IEC-60134
Rep Pk Reverse Voltage-Max 40 V
Reverse Current-Max 100 µA
Reverse Recovery Time-Max 0.0029 µs
Reverse Test Voltage 40 V
Surface Mount YES
Technology SCHOTTKY
Terminal Form NO LEAD
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 30
