PMBT3906YS,115 Information

PMBT3906YS,115 by Nexperia is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for PMBT3906YS,115

Part # Distributor Description Stock Price Buy
DISTI # 1727-PMBT3906YS,115CT-ND
DigiKey TRANS 2PNP 40V 200MA 6-TSSOP Min Qty: 1 Lead time: 6 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 1915
In Stock
  • 1 $0.2600
  • 10 $0.1560
  • 100 $0.0970
  • 500 $0.0712
  • 1,000 $0.0629
  • 3,000 $0.0403
  • 6,000 $0.0360
  • 9,000 $0.0338
  • 15,000 $0.0313
  • 21,000 $0.0298
  • 30,000 $0.0284
  • 75,000 $0.0253
  • 150,000 $0.0233
  • 300,000 $0.0217
$0.0217 / $0.2600 Buy Now
DISTI # PMBT3906YS,115
Avnet Americas Trans GP BJT PNP 40V 0.2A 6-Pin TSSOP T/R - Tape and Reel (Alt: PMBT3906YS,115) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 6 Weeks, 0 Days Container: Reel 120000
  • 3,000 $0.0343
$0.0343 Buy Now
DISTI # 771-PMBT3906YS115
Mouser Electronics Bipolar Transistors - BJT 40 V, 200 mA PNP/PNP general-purpose double transistor RoHS: Compliant 8919
  • 1 $0.2500
  • 10 $0.1540
  • 100 $0.0970
  • 500 $0.0610
  • 1,000 $0.0570
  • 3,000 $0.0430
  • 6,000 $0.0380
  • 9,000 $0.0290
  • 24,000 $0.0270
$0.0270 / $0.2500 Buy Now
DISTI # 88103620
Verical Trans GP BJT PNP 40V 0.2A 350mW 6-Pin TSSOP T/R RoHS: Compliant Min Qty: 11195 Package Multiple: 1 Date Code: 2301 Americas - 39000
  • 11,195 $0.0335
$0.0335 Buy Now
DISTI # 88103619
Verical Trans GP BJT PNP 40V 0.2A 350mW 6-Pin TSSOP T/R RoHS: Compliant Min Qty: 11195 Package Multiple: 1 Date Code: 2401 Americas - 27000
  • 11,195 $0.0335
$0.0335 Buy Now
DISTI # 88044937
Verical Trans GP BJT PNP 40V 0.2A 350mW 6-Pin TSSOP T/R RoHS: Compliant Min Qty: 11195 Package Multiple: 1 Date Code: 1901 Americas - 15000
  • 11,195 $0.0335
$0.0335 Buy Now
Rochester Electronics Small Signal Bipolar Transistor, 0.2A, 40V, 2-Element, PNP RoHS: Compliant Status: Active Min Qty: 1 81000
  • 100 $0.0268
  • 500 $0.0241
  • 1,000 $0.0222
  • 10,000 $0.0198
  • 100,000 $0.0166
$0.0166 / $0.0268 Buy Now
DISTI # PMBT3906YS,115
Avnet Asia Trans GP BJT PNP 40V 0.2A 6-Pin TSSOP T/R (Alt: PMBT3906YS,115) RoHS: Compliant Min Qty: 36000 Package Multiple: 3000 Lead time: 6 Weeks, 0 Days 0
  • 36,000 $0.0225
  • 72,000 $0.0218
  • 108,000 $0.0211
  • 180,000 $0.0205
  • 360,000 $0.0198
  • 900,000 $0.0191
  • 1,800,000 $0.0185
$0.0185 / $0.0225 Buy Now
DISTI # PMBT3906YS,115
Avnet Silica Trans GP BJT PNP 40V 02A 6Pin TSSOP TR (Alt: PMBT3906YS,115) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days Silica - 0
Buy Now
DISTI # PMBT3906YS,115
EBV Elektronik Trans GP BJT PNP 40V 02A 6Pin TSSOP TR (Alt: PMBT3906YS,115) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days EBV - 0
Buy Now
New Advantage Corporation   RoHS: Compliant Min Qty: 1 Package Multiple: 3000 21000
  • 6,000 $0.0303
  • 21,000 $0.0280
$0.0280 / $0.0303 Buy Now

Part Details for PMBT3906YS,115

PMBT3906YS,115 Part Data Attributes

Parametric Data
PMBT3906YS,115 Nexperia
Buy Now Datasheet
Compare Parts:
PMBT3906YS,115 Nexperia PMBT3906YS - 40 V, 200 mA PNP/PNP matched double transistors@en-us TSSOP 6-Pin
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer NEXPERIA
Part Package Code TSSOP
Package Description SC-88, 6 PIN
Pin Count 6
Manufacturer Package Code SOT363
Reach Compliance Code compliant
ECCN Code EAR99
Factory Lead Time 6 Weeks
Date Of Intro 2017-02-01
Samacsys Manufacturer Nexperia
Collector Current-Max (IC) 0.2 A
Collector-Emitter Voltage-Max 40 V
Configuration SEPARATE, 2 ELEMENTS
DC Current Gain-Min (hFE) 30
JESD-30 Code R-PDSO-G6
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 2
Number of Terminals 6
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type PNP
Surface Mount YES
Terminal Finish TIN
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Transistor Application SWITCHING
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 250 MHz
Turn-off Time-Max (toff) 300 ns
Turn-on Time-Max (ton) 70 ns

PMBT3906YS,115 Frequently Asked Questions (FAQ)

  • The recommended PCB footprint for PMBT3906YS,115 is a standard SOT23 package with a 1.3mm x 1.3mm body size and a 0.5mm pitch. The datasheet provides a recommended PCB footprint diagram, but it's essential to consult the Nexperia application note for detailed guidelines.

  • To ensure reliability in high-temperature applications, follow Nexperia's recommended derating guidelines for the PMBT3906YS,115. This includes reducing the maximum junction temperature (Tj) and ensuring proper thermal management, such as using a heat sink or thermal interface material.

  • The maximum allowed voltage on the input pins of the PMBT3906YS,115 is the voltage rating of the device, which is 40V. However, it's essential to consider the maximum voltage rating of the specific application and ensure that the device is operated within the recommended voltage range.

  • Yes, the PMBT3906YS,115 can be used in switching regulator applications. However, it's crucial to ensure that the device is operated within its recommended switching frequency range and that the application is designed to minimize electromagnetic interference (EMI).

  • To handle ESD protection for the PMBT3906YS,115, follow Nexperia's recommended ESD protection guidelines, which include using ESD protection devices, such as TVS diodes, and implementing proper PCB design and handling practices to minimize the risk of ESD damage.
