PJT138K_R1_00001 Information
PJT138K_R1_00001 by PanJit Semiconductor is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| 84000012A | Texas Instruments | Dual J-K Positive-Edge-Triggered Flip-Flops With Clear And Preset 20-LCCC -55 to 125 | |
| 8400001EA | Texas Instruments | Dual J-K Positive-Edge-Triggered Flip-Flops With Clear And Preset 16-CDIP -55 to 125 |
Price & Stock for PJT138K_R1_00001
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
241-PJT138K_R1_00001
|
Mouser Electronics | MOSFETs 50V N-Channel Enhancement Mode MOSFETESD Protected RoHS: Compliant | 74267 |
|
$0.0270 / $0.1600 | Buy Now |
|
DISTI #
87656527
|
Verical | PJT138K_R1_00001 Min Qty: 1169 Package Multiple: 1 | Americas - 3000 |
|
$0.0545 / $0.1060 | Buy Now |
|
|
NAC | 50V N-Channel Enhancement Mode MOSFET�ESD Protected RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Container: Reel | 0 |
|
$0.0220 / $0.0260 | Buy Now |
|
DISTI #
PJT138K_R1_00001
|
Avnet Silica | Trans MOSFET N 50V 036A 6Pin SOT363 TR (Alt: PJT138K_R1_00001) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 27 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Cytech Systems Limited | 50V N-CHANNEL ENHANCEMENT MODE M | 1000 |
|
RFQ | |
|
|
Win Source Electronics | 50V N-CHANNEL ENHANCEMENT MODE M | 16380 |
|
$0.0595 / $0.0767 | Buy Now |
Part Details for PJT138K_R1_00001
PJT138K_R1_00001 CAD Models
PJT138K_R1_00001 Part Data Attributes
|
|
PJT138K_R1_00001
PanJit Semiconductor
Buy Now
Datasheet
|
Compare Parts:
PJT138K_R1_00001
PanJit Semiconductor
Small Signal Field-Effect Transistor, 0.36A I(D), 50V, 2-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, GREEN, PLASTIC PACKAGE-6
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | PANJIT INTERNATIONAL INC | |
| Package Description | GREEN, PLASTIC PACKAGE-6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | PANJIT | |
| Configuration | SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 50 V | |
| Drain Current-Max (ID) | 0.36 A | |
| Drain-source On Resistance-Max | 1.6 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 5 pF | |
| JESD-30 Code | R-PDSO-G6 | |
| Number of Elements | 2 | |
| Number of Terminals | 6 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 0.236 W | |
| Surface Mount | YES | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
Alternate Parts for PJT138K_R1_00001
This table gives cross-reference parts and alternative options found for PJT138K_R1_00001. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of PJT138K_R1_00001, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| PJX138K_R2_00002 | PanJit Semiconductor | Check for Price | Small Signal Field-Effect Transistor, 0.35A I(D), 50V, 2-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, GREEN, PLASTIC PACKAGE-6 | PJT138K_R1_00001 vs PJX138K_R2_00002 |
| PJX8838_R1_00002 | PanJit Semiconductor | Check for Price | Small Signal Field-Effect Transistor, 0.36A I(D), 50V, 2-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, GREEN, PLASTIC PACKAGE-6 | PJT138K_R1_00001 vs PJX8838_R1_00002 |
| PJX8838_R1_00001 | PanJit Semiconductor | Check for Price | Small Signal Field-Effect Transistor, | PJT138K_R1_00001 vs PJX8838_R1_00001 |
| PJX8838_R2_00001 | PanJit Semiconductor | Check for Price | Small Signal Field-Effect Transistor, | PJT138K_R1_00001 vs PJX8838_R2_00001 |
| PJX8838_R2_00002 | PanJit Semiconductor | Check for Price | Small Signal Field-Effect Transistor, 0.36A I(D), 50V, 2-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, GREEN, PLASTIC PACKAGE-6 | PJT138K_R1_00001 vs PJX8838_R2_00002 |
