PDZVTFTR4.7B Information
PDZVTFTR4.7B by ROHM Semiconductor is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for PDZVTFTR4.7B
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
94AC7741
|
Newark | Zener Diode, 4.7V, 1W, Sod-128, Zener Voltage Vz Typ:4.7V, Power Dissipation Pd:1W, Diode Case Style:Sod-128, Zener Tolerance ±:-, No. Of Pins:2Pins, Operating Temperature Max:150°C, Product Range:Pdzvtf Series, Automotive Rohs Compliant: Yes |Rohm PDZVTFTR4.7B RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 5672 |
|
$0.1270 / $0.4300 | Buy Now |
|
DISTI #
32AJ8483
|
Newark | Zener Diode, 4.7V, 1W, Sod-128, Zener Voltage Vz Typ:4.7V, Power Dissipation Pd:1W, Diode Case Style:Sod-128, Zener Tolerance ±:-, No. Of Pins:2Pins, Operating Temperature Max:150°C, Product Range:Pdzvtf Series, Automotive Rohs Compliant: Yes |Rohm PDZVTFTR4.7B RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 1 Container: Reel | 0 |
|
$0.0920 / $0.1000 | Buy Now |
|
DISTI #
PDZVTFTR4.7BCT-ND
|
DigiKey | DIODE ZENER 4.95V 1W PMDTM Min Qty: 1 Lead time: 17 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
3221 In Stock |
|
$0.0925 / $0.4300 | Buy Now |
|
DISTI #
755-PDZVTFTR4.7B
|
Mouser Electronics | Zener Diodes 4.7-5.2V 40mA SOD-128, PMDTM RoHS: Compliant | 2196 |
|
$0.0920 / $0.4300 | Buy Now |
|
DISTI #
68506146
|
Verical | Zener Diode Single 4.95V 5% 10Ohm 1000mW Automotive 2-Pin PMDT-M T/R Min Qty: 421 Package Multiple: 1 Date Code: 2301 | Americas - 1950 |
|
$0.1739 / $0.1865 | Buy Now |
|
DISTI #
69266485
|
Verical | Zener Diode Single 4.95V 5% 10Ohm 1000mW Automotive 2-Pin PMDT-M T/R Min Qty: 315 Package Multiple: 1 Date Code: 2311 | Americas - 1850 |
|
$0.1850 / $0.4120 | Buy Now |
|
DISTI #
41977494
|
Verical | Zener Diode Single 4.95V 5% 10Ohm 1000mW Automotive 2-Pin PMDT-M T/R Min Qty: 280 Package Multiple: 1 Date Code: 1701 | Americas - 280 |
|
$0.2506 | Buy Now |
|
|
Quest Components | 1784 |
|
$0.2080 / $0.5200 | Buy Now | |
|
DISTI #
PDZVTFTR4.7B
|
Avnet Asia | Diode Zener Single 4.7V 1000mW 2-Pin SOD-128 Emboss T/R (Alt: PDZVTFTR4.7B) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks, 0 Days | 0 |
|
RFQ |
Part Details for PDZVTFTR4.7B
PDZVTFTR4.7B CAD Models
PDZVTFTR4.7B Part Data Attributes
|
|
PDZVTFTR4.7B
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
PDZVTFTR4.7B
ROHM Semiconductor
Zener Diode,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 22 Weeks | |
| Date Of Intro | 2017-04-04 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH RELIABILITY | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 1 W | |
| Reference Standard | AEC-Q101 | |
| Reference Voltage-Nom | 4.7 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tol-Max | 5.06% | |
| Working Test Current | 40 mA |
