PDZ3.6BF Information
PDZ3.6BF by Nexperia is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for PDZ3.6BF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
1727-PDZ3.6BFCT-ND
|
DigiKey | DIODE ZENER 3.6V 400MW SOD323 Min Qty: 1 Lead time: 8 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
9935 In Stock |
|
$0.0150 / $0.1700 | Buy Now |
|
DISTI #
PDZ3.6BF
|
Avnet Americas | Diode Zener Single 3.85V 2% 400mW 2-Pin SOD-323 T/R - Tape and Reel (Alt: PDZ3.6BF) RoHS: Compliant Min Qty: 50000 Package Multiple: 10000 Lead time: 8 Weeks, 0 Days Container: Reel | 0 |
|
$0.0202 / $0.0206 | Buy Now |
|
DISTI #
771-PDZ36BF
|
Mouser Electronics | Zener Diodes Single Zener diodes in a SOD123 package RoHS: Compliant | 0 |
|
$0.0150 / $0.1700 | Order Now |
|
DISTI #
PDZ3.6BF
|
TTI | Zener Diodes Single Zener diodes in a SOD123 package RoHS: Compliant pbFree: Pb-Free Min Qty: 30000 Package Multiple: 10000 Container: Reel | Americas - 0 |
|
$0.0132 / $0.0146 | Buy Now |
Part Details for PDZ3.6BF
PDZ3.6BF CAD Models
PDZ3.6BF Part Data Attributes
|
|
PDZ3.6BF
Nexperia
Buy Now
Datasheet
|
Compare Parts:
PDZ3.6BF
Nexperia
PDZ-B series - Single Zener diodes@en-us SOD 2-Pin
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NEXPERIA | |
| Part Package Code | SOD | |
| Package Description | SC-76, 2 PIN | |
| Pin Count | 2 | |
| Manufacturer Package Code | SOD323 | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | Nexperia | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| JESD-30 Code | R-PDSO-G2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.4 W | |
| Reference Standard | IEC-60134 | |
| Reference Voltage-Nom | 3.6 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Finish | TIN | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tol-Max | 2% | |
| Working Test Current | 5 mA |
