PDTC143ZM,315 by:

PDTC143ZM - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ@en-us DFN 3-Pin

Part Details for PDTC143ZM,315 by Nexperia

Results Overview of PDTC143ZM,315 by Nexperia

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Aerospace and Defense Energy and Power Systems Renewable Energy

PDTC143ZM,315 Information

PDTC143ZM,315 by Nexperia is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for PDTC143ZM,315

Part # Distributor Description Stock Price Buy
DISTI # 1727-3044-1-ND
DigiKey TRANS PREBIAS NPN 50V SOT883 Min Qty: 1 Lead time: 8 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) 584
In Stock
  • 1 $0.2200
  • 10 $0.1360
  • 100 $0.0840
  • 500 $0.0615
  • 1,000 $0.0541
  • 2,000 $0.0480
  • 5,000 $0.0413
  • 10,000 $0.0371
  • 20,000 $0.0336
  • 30,000 $0.0318
  • 50,000 $0.0298
  • 70,000 $0.0286
  • 100,000 $0.0274
  • 250,000 $0.0249
$0.0249 / $0.2200 Buy Now
DISTI # PDTC143ZM,315
Avnet Americas Trans Digital BJT NPN 50V 100mA 3-Pin DFN T/R - Tape and Reel (Alt: PDTC143ZM,315) RoHS: Compliant Min Qty: 30000 Package Multiple: 30000 Lead time: 8 Weeks, 0 Days Container: Reel 0
  • 30,000 $0.0229
  • 60,000 $0.0219
  • 120,000 $0.0214
  • 180,000 $0.0212
  • 240,000 $0.0211
$0.0211 / $0.0229 Buy Now
DISTI # 771-PDTC143ZM315
Mouser Electronics Digital Transistors NPN resistor-equipped transistor, R1 = 4.7 kohm, R2 = 47 kohm RoHS: Compliant 25399
  • 1 $0.2200
  • 10 $0.1360
  • 100 $0.0840
  • 500 $0.0620
  • 1,000 $0.0510
  • 5,000 $0.0440
  • 10,000 $0.0400
  • 20,000 $0.0300
$0.0300 / $0.2200 Buy Now
DISTI # 86022155
Verical Trans Digital BJT NPN 50V 0.1A 250mW 3-Pin DFN T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 13637 Package Multiple: 1 Date Code: 2201 Americas - 14630
  • 13,637 $0.0275
  • 100,000 $0.0230
$0.0230 / $0.0275 Buy Now
Rochester Electronics PDTC143ZM - Small Signal Bipolar Transistor, 0.1A, 50V, NPN, XQFN3 RoHS: Compliant Status: Active Min Qty: 1 25591
  • 100 $0.0297
  • 500 $0.0267
  • 1,000 $0.0247
  • 10,000 $0.0220
  • 100,000 $0.0184
$0.0184 / $0.0297 Buy Now
DISTI # PDTC143ZM,315
Avnet Asia Trans Digital BJT NPN 50V 100mA 3-Pin DFN T/R (Alt: PDTC143ZM,315) RoHS: Compliant Min Qty: 30000 Package Multiple: 10000 Lead time: 8 Weeks, 0 Days 0
  • 30,000 $0.0334
  • 60,000 $0.0330
  • 90,000 $0.0326
  • 150,000 $0.0321
  • 300,000 $0.0314
  • 750,000 $0.0306
  • 1,500,000 $0.0299
$0.0299 / $0.0334 Buy Now
DISTI # PDTC143ZM,315
Avnet Silica Trans Digital BJT NPN 50V 100mA 3Pin DFN TR (Alt: PDTC143ZM,315) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 10 Weeks, 0 Days Silica - 0
Buy Now
DISTI # PDTC143ZM,315
EBV Elektronik Trans Digital BJT NPN 50V 100mA 3Pin DFN TR (Alt: PDTC143ZM,315) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 10 Weeks, 0 Days EBV - 20000
Buy Now

Part Details for PDTC143ZM,315

PDTC143ZM,315 Part Data Attributes

Parametric Data
PDTC143ZM,315 Nexperia
Buy Now Datasheet
Compare Parts:
PDTC143ZM,315 Nexperia PDTC143ZM - 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47  kΩ@en-us DFN 3-Pin
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer NEXPERIA
Part Package Code DFN
Package Description SC-101, 3 PIN
Pin Count 3
Manufacturer Package Code SOT883
Reach Compliance Code compliant
ECCN Code EAR99
Factory Lead Time 8 Weeks
Samacsys Manufacturer Nexperia
Additional Feature BUILT-IN BIAS RESISTOR RATIO IS 10
Case Connection COLLECTOR
Collector Current-Max (IC) 0.1 A
Collector-Emitter Voltage-Max 50 V
Configuration SINGLE WITH BUILT-IN RESISTOR
DC Current Gain-Min (hFE) 100
JESD-30 Code R-PBCC-N3
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style CHIP CARRIER
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type NPN
Qualification Status Not Qualified
Surface Mount YES
Terminal Finish TIN
Terminal Form NO LEAD
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 30
Transistor Application SWITCHING
Transistor Element Material SILICON

Alternate Parts for PDTC143ZM,315

This table gives cross-reference parts and alternative options found for PDTC143ZM,315. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of PDTC143ZM,315, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
PDTC143ZMB Nexperia Check for Price Small Signal Bipolar Transistor PDTC143ZM,315 vs PDTC143ZMB
PDTC143ZM NXP Semiconductors Check for Price TRANSISTOR 100 mA, 50 V, NPN, Si, SMALL SIGNAL TRANSISTOR, 1 X 0.60 MM, 0.50 MM HEIGHT, LEADLESS, PLASTIC, SC-101, 3 PIN, BIP General Purpose Small Signal PDTC143ZM,315 vs PDTC143ZM
PDTC143ZM,315 NXP Semiconductors Check for Price PDTC143Z series - NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ DFN 3-Pin PDTC143ZM,315 vs PDTC143ZM,315
