Part Details for NTP5864NG by onsemi
Results Overview of NTP5864NG by onsemi
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
NTP5864NG Information
NTP5864NG by onsemi is a Power Field-Effect Transistor.
