NTHS0805N02N5001JE Information
NTHS0805N02N5001JE by Vishay Intertechnologies is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for NTHS0805N02N5001JE
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
46M2568
|
Newark | Ntc Thermistor, Full Reel, Thermistor Type:Ntc, Resistance (25°C):5Kohm, Product Range:Nths Series, B-Constant:3477K, B-Constant Tolerance:± 3%, Probe Material:-, Lead Length:-, Operating Temperature Min:-40°C, Qualification:- Rohs Compliant: Yes |Vishay NTHS0805N02N5001JE RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$4.2000 / $5.0200 | Buy Now |
|
DISTI #
68AC5692
|
Newark | Ntc Thermistor, 5K, 0805, Thermistor Type:Chip, Resistance (25°C):5Kohm, Product Range:Nths Series, B-Constant:3477K, B-Constant Tolerance:± 3%, Probe Material:-, Lead Length:-, Operating Temperature Min:-40°C, Qualification:- Rohs Compliant: Yes |Vishay NTHS0805N02N5001JE RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$6.1000 | Buy Now |
|
DISTI #
NTHS0805N02N5001JE
|
Avnet Americas | Thermistor NTC 5000Ohm ?5% 2-Pin SMD T/R - Tape and Reel (Alt: NTHS0805N02N5001JE) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 111 Weeks, 0 Days Container: Reel | 0 |
|
$3.1294 / $4.1783 | Buy Now |
|
DISTI #
71-NTHS0805N2N5001JE
|
Mouser Electronics | NTC Thermistors 5Kohms 5% RoHS: Compliant | 4523 |
|
$3.9400 | Buy Now |
|
DISTI #
V72:2272_09470625
|
Arrow Electronics | Thermistor NTC 5K Ohm 5% 2-Pin 0805 Surface Mount Solder Pad 3486K -4 to -3.5 T/R Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2031 Container: Cut Strips | Americas - 40 |
|
$3.9321 | Buy Now |
|
DISTI #
41800623
|
Verical | Thermistor NTC 5K Ohm 5% 2-Pin 0805 Surface Mount Solder Pad 3486K -4 to -3.5 T/R Min Qty: 9 Package Multiple: 1 Date Code: 2031 | Americas - 40 |
|
$3.9321 | Buy Now |
|
DISTI #
NTHS0805N02N5001JE
|
Avnet Abacus | Thermistor NTC 5000Ohm 5 2Pin SMD TR (Alt: NTHS0805N02N5001JE) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 143 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for NTHS0805N02N5001JE
NTHS0805N02N5001JE CAD Models
NTHS0805N02N5001JE Part Data Attributes
|
|
NTHS0805N02N5001JE
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
NTHS0805N02N5001JE
Vishay Intertechnologies
NTC Thermistor, 5000ohm, Surface Mount, CHIP, 0805, HALOGEN FREE AND ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.40.80.70 | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | Vishay | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 1.45 mm | |
| Package Length | 2.01 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 1.25 mm | |
| Packing Method | TR | |
| Rated Power Dissipation (P) | 0.21 W | |
| Rated Temperature | 25 °C | |
| Resistance | 5000 Ω | |
| Resistor Type | NTC THERMISTOR | |
| Surface Mount | YES | |
| Terminal Finish | TIN OVER NICKEL | |
| Terminal Placement | DUAL ENDED | |
| Terminal Shape | WRAPAROUND | |
| Thermal Sensitivity Index | 3486 K | |
| Thermistor Application | TEMPERATURE SENSING | |
| Tolerance | 5% |
