3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for NTCLE100E3104JB0A by Vishay Intertechnologies
Results Overview of NTCLE100E3104JB0A by Vishay Intertechnologies
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
NTCLE100E3104JB0A Information
NTCLE100E3104JB0A by Vishay Intertechnologies is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for NTCLE100E3104JB0A
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
26AH6326
|
Newark | Ntc Thermistor, 100K, Radial Leaded, Zero Power Resistance At 25°C:100Kohm, Product Range:Ntcle Series, Thermistor Mounting:Through Hole, Beta Value (K):4190K, Thermistor Case Style:-, Thermistor Terminals:Radial Leaded, Operating Rohs Compliant: Yes |Vishay NTCLE100E3104JB0A RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$0.2990 / $0.4750 | Buy Now |
|
DISTI #
NTCLE100E3104JB0A
|
Avnet Americas | NTC Cu 0.6 ld coded 100K 5% bulk e3 A - Bulk (Alt: NTCLE100E3104JB0A) RoHS: Compliant Min Qty: 2000 Package Multiple: 500 Lead time: 12 Weeks, 0 Days Container: Bulk | 0 |
|
$0.2120 | Buy Now |
|
DISTI #
594-NTCL100E3104JB0A
|
Mouser Electronics | NTC Thermistors NTC Cu 0.6 ld coded 100K 5% RoHS: Compliant | 11258 |
|
$0.2840 / $0.4600 | Buy Now |
|
DISTI #
NTCLE100E3104JB0A
|
TTI | NTC Thermistors NTC Cu 0.6 ld coded 100K 5% pbFree: Pb-Free Min Qty: 2000 Package Multiple: 500 Container: Bulk | Americas - 0 |
|
$0.2380 | Buy Now |
|
DISTI #
NTCLE100E3104JB0A
|
TTI | NTC Thermistors NTC Cu 0.6 ld coded 100K 5% pbFree: Pb-Free Min Qty: 2000 Package Multiple: 500 Container: Bulk | Americas - 0 |
|
$0.2380 | Buy Now |
|
|
Future Electronics | NTC Thermistor 100k Bead Min Qty: 500 Package Multiple: 500 |
2000 null |
|
$0.1890 / $0.2000 | Buy Now |
|
DISTI #
NTCLE100E3104JB0A
|
TME | NTC thermistor, 100kΩ, THT, 4190K, -40÷125°C, ±5%, 500mW Min Qty: 1 | 1562 |
|
$0.2290 / $0.7490 | Buy Now |
|
DISTI #
NTCLE100E3104JB0A
|
Avnet Abacus | NTC Cu 06 ld coded 100K 5 bulk e3 A (Alt: NTCLE100E3104JB0A) RoHS: Compliant Min Qty: 2000 Package Multiple: 500 Lead time: 15 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for NTCLE100E3104JB0A
NTCLE100E3104JB0A CAD Models
NTCLE100E3104JB0A Part Data Attributes
|
|
NTCLE100E3104JB0A
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
NTCLE100E3104JB0A
Vishay Intertechnologies
NTC Thermistor, 100000ohm, Through Hole Mount, RADIAL LEADED
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | RADIAL LEADED | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Vishay | |
| JESD-609 Code | e3 | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Height | 9 mm | |
| Package Length | 3.3 mm | |
| Package Style | Radial | |
| Package Width | 3 mm | |
| Packing Method | BULK | |
| Rated Power Dissipation (P) | 0.5 W | |
| Rated Temperature | 55 °C | |
| Reference Standard | CUL; UL | |
| Resistance | 100000 Ω | |
| Resistor Type | NTC THERMISTOR | |
| Surface Mount | NO | |
| Terminal Finish | MATTE TIN | |
| Terminal Placement | RADIAL | |
| Terminal Shape | WIRE | |
| Thermal Sensitivity Index | 4190 K | |
| Thermistor Application | TEMPERATURE SENSING | |
| Tolerance | 5% |
NTCLE100E3104JB0A Frequently Asked Questions (FAQ)
-
The recommended storage temperature range for NTCLE100E3104JB0A is -40°C to 150°C.
-
Yes, NTCLE100E3104JB0A is designed to operate in humid environments, but it's recommended to follow the guidelines for moisture sensitivity level (MSL) to prevent damage during assembly and storage.
-
Vishay recommends following standard ESD handling procedures, such as using an ESD wrist strap or mat, and storing the components in ESD-protective packaging to prevent damage.
-
The thermal resistance of the NTCLE100E3104JB0A is not explicitly stated in the datasheet, but it can be estimated based on the package type and material. For a 1206 package, the thermal resistance is typically around 10-20°C/W.
-
Yes, NTCLE100E3104JB0A is designed to withstand vibrations, but it's recommended to follow the guidelines for vibration testing and ensure that the component is properly secured to the PCB to prevent damage.
