NSV45035JZT1G Information
NSV45035JZT1G by onsemi is a Display Driver.
Display Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for NSV45035JZT1G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
31AC1010
|
Newark | Led Driver, Aec-Q101, Cc, Sot-223-4, Device Topology:Constant Current, No. Of Outputs:1Outputs, Output Current:70Ma, Output Voltage:-, Driver Case Style:Sot-223, No. Of Pins:4Pins, Input Voltage Min:-, Input Voltage Max:45V, Rohs Compliant: Yes |Onsemi NSV45035JZT1G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 997 |
|
$0.3120 / $1.0600 | Buy Now |
|
DISTI #
11X3685
|
Newark | Led Driver, Adjustable Constant Current Regulator, 45 V, 35 Ma/ Reel |Onsemi NSV45035JZT1G RoHS: Not Compliant Min Qty: 1000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.2100 / $0.2770 | Buy Now |
|
DISTI #
NSV45035JZT1GOSCT-ND
|
DigiKey | IC CURRENT REGULATOR 15% SOT223 Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1990 In Stock |
|
$0.2103 / $0.5100 | Buy Now |
|
DISTI #
NSV45035JZT1G
|
Avnet Americas | LED Driver, Adjustable Constant Current, AEC-Q101, 1 Output, 45V In, 35mA to 70mA Out, SOT-223-4 - Tape and Reel (Alt: NSV45035JZT1G) RoHS: Compliant Min Qty: 4000 Package Multiple: 1000 Lead time: 12 Weeks, 0 Days Container: Reel | 0 |
|
$0.2026 / $0.2211 | Buy Now |
|
DISTI #
863-NSV45035JZT1G
|
Mouser Electronics | LED Lighting Driver ICs LED Dvr Adj Constant Crnt Reg 45V 35mA RoHS: Compliant | 1740 |
|
$0.1960 / $1.0600 | Buy Now |
|
DISTI #
V36:1790_07297257
|
Arrow Electronics | LED Driver 80 Segment 4-Pin(3+Tab) SOT-223 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 12 Weeks Date Code: 2506 | Americas - 3000 |
|
$0.1956 / $0.2427 | Buy Now |
|
DISTI #
V72:2272_07297257
|
Arrow Electronics | LED Driver 80 Segment 4-Pin(3+Tab) SOT-223 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2131 Container: Cut Strips | Americas - 340 |
|
$0.2451 / $0.2488 | Buy Now |
|
|
Onlinecomponents.com | LED Driver, Adjustable Constant Current Regulator, 45 V, 35 mA RoHS: Compliant |
1975 Partner Stock |
|
$0.1895 / $0.2151 | Buy Now |
|
DISTI #
89523039
|
Verical | LED Driver 80 Segment 4-Pin(3+Tab) SOT-223 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Date Code: 2506 | Americas - 3000 |
|
$0.2427 | Buy Now |
|
|
Chip 1 Exchange | INSTOCK | 1300 |
|
RFQ |
Part Details for NSV45035JZT1G
NSV45035JZT1G CAD Models
NSV45035JZT1G Part Data Attributes
|
|
NSV45035JZT1G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NSV45035JZT1G
onsemi
LED Driver, Adjustable Constant Current Regulator, 45 V, 35 mA, SOT-223 (TO-261) 4 LEAD, 1000-REEL, Automotive Qualified
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOT-223 (TO-261) 4 LEAD | |
| Package Description | SOT-223, 4 PIN | |
| Pin Count | 4 | |
| Manufacturer Package Code | 0.0318 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Input Characteristics | STANDARD | |
| Interface IC Type | LED DISPLAY DRIVER | |
| JESD-30 Code | R-PDSO-G4 | |
| JESD-609 Code | e3 | |
| Length | 6.5 mm | |
| Moisture Sensitivity Level | 1 | |
| Multiplexed Display Capability | NO | |
| Number of Functions | 1 | |
| Number of Segments | 3 | |
| Number of Terminals | 4 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Polarity | TRUE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOT-223 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Screening Level | AEC-Q101 | |
| Seated Height-Max | 1.75 mm | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 2.3 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.5 mm |
NSV45035JZT1G Frequently Asked Questions (FAQ)
-
A thermal pad is recommended under the package to improve thermal performance. A minimum of 2 oz copper thickness is recommended for the thermal pad, and it should be connected to a solid ground plane to dissipate heat efficiently.
-
Ensure that the device is operated within the recommended temperature range (-40°C to 150°C). Use a heat sink or thermal interface material to improve heat dissipation. Also, ensure that the device is not exposed to moisture or humidity, which can affect reliability.
-
A ceramic capacitor with a value of 1-10 μF is recommended for input decoupling. The capacitor should be placed as close to the device as possible to minimize noise and ensure stable operation.
-
Use a TVS (Transient Voltage Suppressor) diode or a zener diode to protect the device from overvoltage. For overcurrent protection, use a fuse or a PTC (Positive Temperature Coefficient) thermistor in series with the input voltage.
-
A ceramic capacitor with a value of 1-10 μF is recommended for output filtering. The capacitor should be placed as close to the device as possible to minimize noise and ensure stable operation.
