Part Details for NSD914XV2T1G by onsemi
Results Overview of NSD914XV2T1G by onsemi
- Distributor Offerings: (25 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
NSD914XV2T1G Information
NSD914XV2T1G by onsemi is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for NSD914XV2T1G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
81AC9539
|
Newark | Ss Sod523 Swch Diode Tr Rohs Compliant: Yes |Onsemi NSD914XV2T1G RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 12000 |
|
$0.0480 / $0.0550 | Buy Now |
|
DISTI #
97Y9442
|
Newark | Diode, Small Sig, Aec-Q101, 100V, Sod-523, Diode Configuration:Single, Repetitive Reverse Voltage Vrrm Max:100V, Forward Current If(Av):200Ma, Forward Voltage Vf Max:1V, Reverse Recovery Time Trr Max:4Ns, Forward Surge Current Ifsm Rohs Compliant: Yes |Onsemi NSD914XV2T1G RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 695 |
|
$0.0810 / $0.2080 | Buy Now |
|
DISTI #
85AC2094
|
Newark | Diode, Small Sig, Aec-Q101, 100V, Sod-523, Diode Configuration:Single, Repetitive Reverse Voltage Vrrm Max:100V, Forward Current If(Av):200Ma, Forward Voltage Vf Max:1V, Reverse Recovery Time Trr Max:4Ns, Forward Surge Current Ifsm Rohs Compliant: Yes |Onsemi NSD914XV2T1G RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 1 Container: Reel | 0 |
|
$0.0490 / $0.0550 | Buy Now |
|
DISTI #
NSD914XV2T1GOSCT-ND
|
DigiKey | DIODE STANDARD 100V 200MA SOD523 Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
18000 In Stock |
|
$0.0319 / $0.1900 | Buy Now |
|
DISTI #
NSD914XV2T1G
|
Avnet Americas | Diode Small Signal Switching 100V 0.2A 2-Pin SOD-523 T/R - Tape and Reel (Alt: NSD914XV2T1G) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks, 0 Days Container: Reel | 12000 |
|
$0.0138 / $0.0147 | Buy Now |
|
DISTI #
863-NSD914XV2T1G
|
Mouser Electronics | Small Signal Switching Diodes 100V 200mA RoHS: Compliant | 5909 |
|
$0.0310 / $0.1900 | Buy Now |
|
DISTI #
V36:1790_07310595
|
Arrow Electronics | Diode Small Signal Switching 0.2A 2-Pin SOD-523 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks Date Code: 2423 | Americas - 3000 |
|
$0.0149 / $0.0387 | Buy Now |
|
|
Future Electronics | NSD914XV2T1 Series 200 mA 100 V High-Speed Switching Diode SOD-523 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks Container: Reel | 15000Reel |
|
$0.0158 / $0.0172 | Buy Now |
|
|
Future Electronics | NSD914XV2T1 Series 200 mA 100 V High-Speed Switching Diode SOD-523 RoHS: Compliant pbFree: Yes Min Qty: 21000 Package Multiple: 3000 Lead time: 10 Weeks Container: Reel | 0Reel |
|
$0.0158 / $0.0172 | Buy Now |
|
|
Onlinecomponents.com | 100 V High Speed Switching Diode RoHS: Compliant |
24000 In Stock |
|
$0.0151 / $0.0187 | Buy Now |
Part Details for NSD914XV2T1G
NSD914XV2T1G CAD Models
NSD914XV2T1G Part Data Attributes
|
|
NSD914XV2T1G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NSD914XV2T1G
onsemi
100 V High Speed Switching Diode, SOD-523 2 LEAD, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOD-523 2 LEAD | |
| Package Description | LEAD FREE, PLASTIC, CASE 502-01, 2 PIN | |
| Pin Count | 2 | |
| Manufacturer Package Code | 502 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.70 | |
| Factory Lead Time | 10 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Application | GENERAL PURPOSE | |
| Breakdown Voltage-Min | 100 V | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1 V | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 0.5 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Current-Max | 0.2 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Dissipation-Max | 0.2 W | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 100 V | |
| Reverse Current-Max | 5 µA | |
| Reverse Recovery Time-Max | 0.004 µs | |
| Reverse Test Voltage | 75 V | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
