NJM2072M Information
NJM2072M by New Japan Radio Co Ltd is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for NJM2072M
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Quest Components | SPECIALTY ANALOG CIRCUIT, PDSO8 | 324 |
|
$0.5460 / $2.1000 | Buy Now |
|
|
Win Source Electronics | SIGNAL LEVEL SENSOR SYSTEM | 89200 |
|
$0.6696 / $1.0043 | Buy Now |
Part Details for NJM2072M
NJM2072M CAD Models
NJM2072M Part Data Attributes
|
|
NJM2072M
New Japan Radio Co Ltd
Buy Now
Datasheet
|
Compare Parts:
NJM2072M
New Japan Radio Co Ltd
Analog Circuit, BIPolar, PDSO8, DMP-8
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NEW JAPAN RADIO CO LTD | |
| Part Package Code | SOIC | |
| Package Description | DMP-8 | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | New Japan Radio | |
| Analog IC - Other Type | ANALOG CIRCUIT | |
| JESD-30 Code | S-PDSO-G8 | |
| JESD-609 Code | e6 | |
| Length | 5 mm | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 75 °C | |
| Operating Temperature-Min | -25 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.3 | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.9 mm | |
| Supply Current-Max (Isup) | 1.5 mA | |
| Supply Voltage-Max (Vsup) | 7 V | |
| Supply Voltage-Min (Vsup) | 0.9 V | |
| Supply Voltage-Nom (Vsup) | 3 V | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temperature Grade | COMMERCIAL EXTENDED | |
| Terminal Finish | TIN BISMUTH | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Width | 5 mm |
