Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for NDUL03N150CG by onsemi
Results Overview of NDUL03N150CG by onsemi
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Space Technology
Aerospace and Defense
Energy and Power Systems
NDUL03N150CG Information
NDUL03N150CG by onsemi is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for NDUL03N150CG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
87053915
|
Verical | Trans MOSFET N-CH 1.5KV 2.5A 3-Pin(3+Tab) TO-3PF Tube Min Qty: 156 Package Multiple: 1 Date Code: 2301 | Americas - 1680 |
|
$2.4125 | Buy Now |
|
DISTI #
87805311
|
Verical | Trans MOSFET N-CH 1.5KV 2.5A 3-Pin(3+Tab) TO-3PF Tube Min Qty: 156 Package Multiple: 1 Date Code: 2201 | Americas - 540 |
|
$2.4125 | Buy Now |
|
|
Rochester Electronics | NDUL03N150C - N-Channel Power MOSFET, 1500V, 2.5A RoHS: Not Compliant Status: End of Life / Last Time Buy Min Qty: 1 | 2220 |
|
$1.5400 / $1.9300 | Buy Now |
|
DISTI #
NDUL03N150CG
|
TME | Transistor: N-MOSFET, unipolar, 1500V, 2.5A, 50W, TO3PF Min Qty: 1 | 0 |
|
$2.2300 / $3.3400 | RFQ |
|
DISTI #
NDUL03N150CG
|
Avnet Silica | Power MOSFET N Channel 15 kV 25 A 8 ohm TO3PF Through Hole (Alt: NDUL03N150CG) RoHS: Compliant Min Qty: 30 Package Multiple: 30 Lead time: 143 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Cytech Systems Limited | MOSFET N-CH 1500V 2.5A TO3P | 360 |
|
RFQ | |
|
DISTI #
NDUL03N150CG
|
EBV Elektronik | Power MOSFET N Channel 15 kV 25 A 8 ohm TO3PF Through Hole (Alt: NDUL03N150CG) RoHS: Compliant Min Qty: 30 Package Multiple: 30 Lead time: 143 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
DISTI #
NDUL03N150CG
|
EBV Elektronik | Power MOSFET N Channel 15 kV 25 A 8 ohm TO3PF Through Hole (Alt: NDUL03N150CG) RoHS: Compliant Min Qty: 30 Package Multiple: 30 Lead time: 143 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for NDUL03N150CG
NDUL03N150CG CAD Models
NDUL03N150CG Part Data Attributes
|
|
NDUL03N150CG
onsemi
Buy Now
Datasheet
|
Compare Parts:
NDUL03N150CG
onsemi
N-Channel Power MOSFET, 1500V, 2.5A, 10.5Ω, TO-3PF-3L, 30-TUBE
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | TO-3PF-3L | |
| Package Description | TO-3PF, SC-94, 3 PIN | |
| Pin Count | 3 | |
| Manufacturer Package Code | 340AH | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | onsemi | |
| Avalanche Energy Rating (Eas) | 34 mJ | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 1500 V | |
| Drain Current-Max (ID) | 2.5 A | |
| Drain-source On Resistance-Max | 10.5 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PSFM-T3 | |
| JESD-609 Code | e3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Polarity/Channel Type | N-CHANNEL | |
| Pulsed Drain Current-Max (IDM) | 5 A | |
| Surface Mount | NO | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Transistor Element Material | SILICON |
NDUL03N150CG Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the NDUL03N150CG is -55°C to 150°C.
-
To ensure reliability, follow the recommended assembly and handling procedures, and ensure that the device is operated within the specified voltage and current ratings. Additionally, consider using a robust PCB design, and implementing adequate thermal management and ESD protection.
-
Yes, the NDUL03N150CG is suitable for high-frequency switching applications due to its low capacitance and inductance. However, ensure that the device is operated within the specified frequency range and that the PCB design is optimized for high-frequency operation.
-
Store the NDUL03N150CG in its original packaging or in a similar anti-static package. Avoid exposing the device to extreme temperatures, humidity, or physical stress. Handle the device by the body, avoiding touching the leads or die.
-
The recommended soldering conditions for the NDUL03N150CG are: peak temperature of 260°C, soldering time of 10 seconds, and a soldering iron temperature of 350°C.
