NCV7750DPR2G by:

4 Channel Low-Side Relay Driver 4 Channel Low-Side Relay Driver, SSOP-24, 2500-REEL, Automotive Qualified

Part Details for NCV7750DPR2G by onsemi

Results Overview of NCV7750DPR2G by onsemi

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation Energy and Power Systems Renewable Energy

NCV7750DPR2G Information

NCV7750DPR2G by onsemi is a Peripheral Driver.
Peripheral Drivers are under the broader part category of Drivers And Interfaces.

A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.

Price & Stock for NCV7750DPR2G

Part # Distributor Description Stock Price Buy
DISTI # 38AH7041
Newark Automotive Driver/ Reel Rohs Compliant: Yes |Onsemi NCV7750DPR2G RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 2,500 $1.2300
  • 5,000 $1.1900
$1.1900 / $1.2300 Buy Now
DISTI # 03AJ2387
Newark Relay Driver, Aec-Q100, -40 To 150Deg C, Output Current:1A, Supply Voltage Min:3V, Supply Voltage Max:5.5V, Driver Case Style:Ssop, No. Of Pins:24Pins, Operating Temperature Min:-40°C, Operating Temperature Max:150°C, Product Rohs Compliant: Yes |Onsemi NCV7750DPR2G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 0
  • 1 $2.7100
$2.7100 Buy Now
DISTI # NCV7750DPR2GOSCT-ND
DigiKey IC PWR DRIVER N-CHAN 1:4 24SSOP Min Qty: 1 Lead time: 16 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) 4475
In Stock
  • 1 $3.6400
  • 10 $2.3290
  • 25 $1.9876
  • 100 $1.6015
  • 250 $1.4118
  • 500 $1.2951
  • 1,000 $1.1974
  • 2,500 $1.1415
$1.1415 / $3.6400 Buy Now
DISTI # NCV7750DPR2G
Avnet Americas Relay Driver 1.3A 4-OUT Lo Side Non-Inv 24-Pin SSOP T/R - Tape and Reel (Alt: NCV7750DPR2G) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 16 Weeks, 0 Days Container: Reel 45000 Factory Stock
  • 2,500 $1.1708
  • 5,000 $1.1415
  • 10,000 $1.1137
  • 15,000 $1.0904
  • 20,000 $1.0848
$1.0848 / $1.1708 Buy Now
DISTI # 863-NCV7750DPR2G
Mouser Electronics Motor / Motion / Ignition Controllers & Drivers AUTOMOTIVE DRIVER RoHS: Compliant 7385
  • 1 $3.6100
  • 10 $2.3300
  • 25 $1.9900
  • 100 $1.6100
  • 250 $1.4200
  • 500 $1.3000
  • 1,000 $1.1900
  • 2,500 $1.1400
$1.1400 / $3.6100 Buy Now
Onlinecomponents.com N-Channel PMIC Automotive, AEC-Q100 Series 24-SSOP (0.154, 3.90mm Width) RoHS: Compliant 0
  • 625 $2.3700
  • 1,250 $1.4600
  • 1,875 $1.1600
  • 2,500 $1.1300
$1.1300 / $2.3700 Buy Now
DISTI # 87654115
Verical Driver 1.3A 4-OUT Low Side Automotive AEC-Q100 24-Pin SSOP N T/R RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Americas - 45000
  • 2,500 $1.1487
$1.1487 Buy Now
DISTI # 88059030
Verical Driver 1.3A 4-OUT Low Side Automotive AEC-Q100 24-Pin SSOP N T/R RoHS: Compliant Min Qty: 100 Package Multiple: 1 Date Code: 1801 Americas - 570
  • 100 $7.9500
$7.9500 Buy Now
Rochester Electronics NCV7750 - 4 Channel Low-Side Relay Driver 4 Channel Low-Side Relay Driver RoHS: Compliant Status: Active Min Qty: 1 570
  • 100 $6.3600
  • 500 $5.7200
  • 1,000 $5.2800
  • 10,000 $4.7100
  • 100,000 $3.9400
$3.9400 / $6.3600 Buy Now
DISTI # NCV7750DPR2G
Richardson RFPD GATE DRIVER IC RoHS: Compliant Min Qty: 2500 0
  • 2,500 $1.1400
$1.1400 Buy Now
DISTI # NCV7750DPR2G
Avnet Silica Relay Driver 13A 4OUT Lo Side NonInv 24Pin SSOP TR (Alt: NCV7750DPR2G) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 17 Weeks, 0 Days Silica - 0
Buy Now
DISTI # NCV7750DPR2G
EBV Elektronik Relay Driver 13A 4OUT Lo Side NonInv 24Pin SSOP TR (Alt: NCV7750DPR2G) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 18 Weeks, 0 Days EBV - 0
Buy Now
Flip Electronics Stock, ship today 47500
RFQ

Part Details for NCV7750DPR2G

NCV7750DPR2G CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

NCV7750DPR2G Part Data Attributes

Parametric Data
NCV7750DPR2G onsemi
Buy Now Datasheet
Compare Parts:
NCV7750DPR2G onsemi 4 Channel Low-Side Relay Driver 4 Channel Low-Side Relay Driver, SSOP-24, 2500-REEL, Automotive Qualified
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ONSEMI
Part Package Code SSOP-24
Package Description SSOP-24
Manufacturer Package Code 565AL
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.39.00.01
Factory Lead Time 16 Weeks
Date Of Intro 2018-12-11
Samacsys Manufacturer onsemi
Additional Feature ALSO OPERATES AT 5V SUPPLY
Built-in Protections OVER CURRENT; THERMAL
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
JESD-30 Code R-PDSO-G24
JESD-609 Code e4
Length 8.65 mm
Moisture Sensitivity Level 2
Number of Functions 4
Number of Terminals 24
Operating Temperature-Max 150 °C
Operating Temperature-Min -40 °C
Output Current Flow Direction SINK
Package Body Material PLASTIC/EPOXY
Package Code SSOP
Package Equivalence Code SSOP24,.24
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Cel) 260
Screening Level AEC-Q100
Seated Height-Max 1.75 mm
Supply Current-Max 0.5 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 3 V
Supply Voltage-Nom 3.3 V
Surface Mount YES
Temperature Grade AUTOMOTIVE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Turn-off Time 50 µs
Turn-on Time 50 µs
Width 3.9 mm
