NCV1117DT33T5G Information
NCV1117DT33T5G by onsemi is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for NCV1117DT33T5G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
90W0782
|
Newark | Fixed Ldo Voltage Regulator, 4.75V To 20V, 1.07V Dropout, 3.3Vout, 1.5Aout, To-252-3 Rohs Compliant: Yes |Onsemi NCV1117DT33T5G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 5569 |
|
$0.2350 / $0.7100 | Buy Now |
|
DISTI #
81AC9515
|
Newark | Ana 1.0 Ldo Regulator Rohs Compliant: Yes |Onsemi NCV1117DT33T5G RoHS: Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1720 | Buy Now |
|
DISTI #
NCV1117DT33T5GOSCT-ND
|
DigiKey | IC REG LINEAR 3.3V 1A DPAK Min Qty: 1 Lead time: 5 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
7469 In Stock |
|
$0.2329 / $1.2000 | Buy Now |
|
DISTI #
NCV1117DT33T5G
|
Avnet Americas | LDO Regulator Pos 3.3V 1A 3-Pin(2+Tab) DPAK T/R - Tape and Reel (Alt: NCV1117DT33T5G) RoHS: Compliant Min Qty: 5000 Package Multiple: 2500 Lead time: 5 Weeks, 0 Days Container: Reel | 0 |
|
$0.1584 / $0.1715 | Buy Now |
|
DISTI #
863-NCV1117DT33T5G
|
Mouser Electronics | LDO Voltage Regulators 3.3V 1.0A Automotive RoHS: Compliant | 8022 |
|
$0.2320 / $1.2000 | Buy Now |
|
DISTI #
E02:0323_00077460
|
Arrow Electronics | LDO Regulator Pos 3.3V 1A Automotive AEC-Q100 3-Pin(2+Tab) DPAK T/R Min Qty: 2500 Package Multiple: 2500 Lead time: 5 Weeks Date Code: 2450 | Europe - 60000 |
|
$0.2134 / $0.2236 | Buy Now |
|
|
Future Electronics | NCV1117 Series 1 A 3.3 V Fixed Output LDO Voltage Regulator - TO-252 RoHS: Compliant pbFree: Yes Min Qty: 2500 Package Multiple: 2500 Lead time: 5 Weeks Container: Reel | 72500Reel |
|
$0.1630 / $0.1700 | Buy Now |
|
|
Future Electronics | NCV1117 Series 1 A 3.3 V Fixed Output LDO Voltage Regulator - TO-252 RoHS: Compliant pbFree: Yes Min Qty: 2500 Package Multiple: 2500 Lead time: 5 Weeks Container: Reel | 12500Reel |
|
$0.1630 / $0.1700 | Buy Now |
|
|
Onlinecomponents.com | Linear Voltage Regulator, 1 A, High PSRR Vout: 3.3 V RoHS: Compliant |
20000 In Stock |
|
$0.2199 / $0.2452 | Buy Now |
|
DISTI #
87284961
|
Verical | LDO Regulator Pos 3.3V 1A Automotive AEC-Q100 3-Pin(2+Tab) DPAK T/R Min Qty: 2500 Package Multiple: 2500 Date Code: 2450 | Americas - 60000 |
|
$0.2134 / $0.2237 | Buy Now |
Part Details for NCV1117DT33T5G
NCV1117DT33T5G CAD Models
NCV1117DT33T5G Part Data Attributes
|
|
NCV1117DT33T5G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NCV1117DT33T5G
onsemi
Linear Voltage Regulator, 1 A, High PSRR Vout: 3.3 V, DPAK (SINGLE GAUGE) TO-252, 2500-REEL, Automotive Qualified
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | DPAK (SINGLE GAUGE) TO-252 | |
| Package Description | DPAK-3/2 | |
| Pin Count | 3 | |
| Manufacturer Package Code | 369C | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 5 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Adjustability | FIXED | |
| Dropout Voltage1-Max | 1.2 V | |
| Dropout Voltage1-Nom | 1.07 V | |
| Input Voltage Absolute-Max | 20 V | |
| Input Voltage-Max | 15 V | |
| Input Voltage-Min | 4.75 V | |
| JESD-30 Code | R-PSSO-G2 | |
| JESD-609 Code | e3 | |
| Length | 6.54 mm | |
| Line Regulation-Max | 0.0045% | |
| Load Regulation-Max | 0.01% | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature TJ-Max | 150 °C | |
| Operating Temperature TJ-Min | -55 °C | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current1-Max | 1 A | |
| Output Voltage1-Max | 3.365 V | |
| Output Voltage1-Min | 3.235 V | |
| Output Voltage1-Nom | 3.3 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TO-252 | |
| Package Equivalence Code | SMSIP3H,.38,90TB | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 2.38 mm | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 2.29 mm | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tolerance-Max | 2% | |
| Width | 6.095 mm |
NCV1117DT33T5G Frequently Asked Questions (FAQ)
-
The maximum input voltage is 15V, but it's recommended to keep it below 12V for optimal performance and to prevent overheating.
-
To ensure stability, a minimum output capacitance of 10uF is recommended, and the ESR (Equivalent Series Resistance) should be less than 5 ohms.
-
The maximum output current is 1A, but it's recommended to keep it below 800mA for optimal performance and to prevent overheating.
-
To prevent overheating, ensure good airflow around the device, use a heat sink if necessary, and keep the input voltage and output current within the recommended ranges.
-
The NCV1117DT33T5G is rated for operation up to 125°C, but the output current and input voltage should be derated at higher temperatures to prevent overheating.
