NCP5106BPG Information
NCP5106BPG by onsemi is a Peripheral Driver.
Peripheral Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for NCP5106BPG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Rochester Electronics | Half Bridge Based Peripheral Driver, PDIP8 RoHS: Compliant Status: Obsolete Min Qty: 1 | 123 |
|
$1.1400 / $1.4300 | Buy Now |
|
DISTI #
NCP5106BPG
|
EBV Elektronik | MOSFET DRVR 05A 2OUT HiLo Side Full BrdgHalf Brdg NonInv 8Pin PDIP Rail (Alt: NCP5106BPG) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 143 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Vyrian | Interface ICs | 123 |
|
RFQ |
Part Details for NCP5106BPG
NCP5106BPG CAD Models
NCP5106BPG Part Data Attributes
|
|
NCP5106BPG
onsemi
Buy Now
Datasheet
|
Compare Parts:
NCP5106BPG
onsemi
MOSFET / IGBT Drivers, High Voltage, High and Low Side, 8 LEAD PDIP, 50-TUBE
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | 8 LEAD PDIP | |
| Pin Count | 8 | |
| Manufacturer Package Code | 626-05 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 4 Weeks | |
| Samacsys Manufacturer | onsemi | |
| High Side Driver | YES | |
| Interface IC Type | HALF BRIDGE BASED IGBT/MOSFET DRIVER | |
| JESD-30 Code | R-PDIP-T8 | |
| JESD-609 Code | e3 | |
| Length | 9.59 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Characteristics | PUSH-PULL | |
| Output Peak Current Limit-Nom | 0.5 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | DIP | |
| Package Equivalence Code | DIP8,.3 | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 5.33 mm | |
| Supply Current-Max | 5 mA | |
| Supply Voltage-Max | 20 V | |
| Supply Voltage-Nom | 15 V | |
| Supply Voltage1-Max | 20 V | |
| Supply Voltage1-Min | 10 V | |
| Supply Voltage1-Nom | 15 V | |
| Surface Mount | NO | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | PIN/PEG | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Turn-off Time | 0.17 µs | |
| Turn-on Time | 0.17 µs | |
| Width | 7.62 mm |
