Part Details for NC7SV157P6X by onsemi
Results Overview of NC7SV157P6X by onsemi
- Distributor Offerings: (32 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
NC7SV157P6X Information
NC7SV157P6X by onsemi is a Multiplexer/Demultiplexer.
Multiplexer/Demultiplexers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for NC7SV157P6X
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
26AC2606
|
Newark | Ulp-A 2-In Non-Inv Mux Rohs Compliant: Yes |Onsemi NC7SV157P6X RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 21000 |
|
$0.0660 | Buy Now |
|
DISTI #
58M9747
|
Newark | Ic, Nc7Sv, Smd, Logic Family/Base Number:Nc7S157, Logic Type:Multiplexer, No. Of Channels:1Channels, Line Configuration:2:1, Supply Voltage Min:900Mv, Supply Voltage Max:3.6V, Logic Case Style:Sc-70, No. Of Pins:6Pins, Logic Ic Rohs Compliant: Yes |Onsemi NC7SV157P6X RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1678 |
|
$0.1810 / $0.5680 | Buy Now |
|
DISTI #
NC7SV157P6XCT-ND
|
DigiKey | IC MULTIPLEXER 1 X 2:1 SC-88 Min Qty: 1 Lead time: 9 Weeks Container: Cut Tape (CT), Digi-ReelĀ®, Tape & Reel (TR) |
5302 In Stock |
|
$0.0853 / $0.2500 | Buy Now |
|
DISTI #
NC7SV157P6X
|
Avnet Americas | Multiplexer, 1 Channels, 2:1, 0.9 V to 3.6 V, SC-70-6 - Tape and Reel (Alt: NC7SV157P6X) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 9 Weeks, 0 Days Container: Reel | 21000 |
|
$0.0599 / $0.0655 | Buy Now |
|
DISTI #
NC7SV157P6X
|
Avnet Americas | Multiplexer, 1 Channels, 2:1, 0.9 V to 3.6 V, SC-70-6 - Tape and Reel (Alt: NC7SV157P6X) RoHS: Compliant Min Qty: 12000 Package Multiple: 3000 Lead time: 111 Weeks, 0 Days Container: Reel | 0 |
|
RFQ | |
|
DISTI #
512-NC7SV157P6X
|
Mouser Electronics | Encoders, Decoders, Multiplexers & Demultiplexers 2-Input Multiplexer RoHS: Compliant | 4433 |
|
$0.0890 / $0.5800 | Buy Now |
|
DISTI #
V36:1790_06303232
|
Arrow Electronics | Multiplexer 1-Element CMOS 2-IN 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 9 Weeks Date Code: 2440 | Americas - 18000 |
|
$0.0581 / $0.1060 | Buy Now |
|
DISTI #
E02:0323_00845432
|
Arrow Electronics | Multiplexer 1-Element CMOS 2-IN 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 9 Weeks Date Code: 2448 | Europe - 9000 |
|
$0.0621 / $0.1075 | Buy Now |
|
DISTI #
V79:2366_17785936
|
Arrow Electronics | Multiplexer 1-Element CMOS 2-IN 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 36 Weeks Date Code: 2216 | Americas - 5900 |
|
$0.0653 / $0.1000 | Buy Now |
|
DISTI #
V72:2272_06303232
|
Arrow Electronics | Multiplexer 1-Element CMOS 2-IN 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 9 Weeks Date Code: 2248 Container: Cut Strips | Americas - 704 |
|
$0.1071 / $0.2500 | Buy Now |
Part Details for NC7SV157P6X
NC7SV157P6X CAD Models
NC7SV157P6X Part Data Attributes
|
|
NC7SV157P6X
onsemi
Buy Now
Datasheet
|
Compare Parts:
NC7SV157P6X
onsemi
TinyLogic ULP-A 2-Input Non-Inverting Multiplexer, SC-88-6 / SC-70-6 / SOT-363-6, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SC-88-6 / SC-70-6 / SOT-363-6 | |
| Package Description | SC-70, 6 PIN | |
| Manufacturer Package Code | 419AD | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 9 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Family | AUP/ULP/V | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e4 | |
| Length | 2 mm | |
| Load Capacitance (CL) | 15 pF | |
| Logic IC Type | MULTIPLEXER | |
| Max I(ol) | 0.002 A | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Inputs | 2 | |
| Number of Outputs | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Polarity | TRUE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP6,.08 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Prop. Delay@Nom-Sup | 18.8 ns | |
| Propagation Delay (tpd) | 18.8 ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 mm | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 0.9 V | |
| Supply Voltage-Nom (Vsup) | 1.2 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.25 mm |
